| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | VMPA2-M1H-G-PI |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD60-80 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 200 pcs per month |
| Model: | VMPA2-M1H-G-PI | Order No: | 537955 |
|---|---|---|---|
| Brand: | FESTO | Valve Function: | 5/3 Closed |
| Valve Size: | 20 Mm | Type Of Actuation: | Electric |
| High Light: | 5/3 Closed Solenoid Air Valve,20mm Pneumatic Solenoid Valves,Wall Mounting Electric Solenoid Air Valve |
||
About product
| Easy to mount | Secure wall mounting |
| Versatile | Wide range of valve functions |
| Innovative | Compact high-performance valves in sturdy metal housing |
Technical Data
| Valve function | 5/3 closed |
| Type of actuation | Electric |
| Valve size | 20 mm |
| Standard nominal flow rate | 610 l/min |
| Operating voltage | 24V DC |
| Design | Piston gate valve |
| Type of reset | Mechanical spring |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP65 To IEC 60529 |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting Non-detenting |
| Type of piloting | Pilot actuated |
| Flow direction | Reversible |
| Symbol | 00991020 |
| lap | Positive overlap |
| Signal status display | yes |
| Suitability for vacuum | yes |
| Standard nominal flow rate with QS-8 | 610 l/min |
| Standard nominal flow rate with QS-10 | 750 l/min |
| Switching time off | 40 ms |
| Switching time on | 10 ms |
| Switching time reversal | 21 ms |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -20°C-40°C |
| Media temperature | -5°C-50°C |
| Ambient temperature | -5°C-50°C |
| Max. tightening torque for valve mounting | 0.65 Nm |
| Product weight | 100 g |
| Type of mounting | With through-hole |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
Another size as below
| Type | Order no | Price |
| VMPA1-M1H-B-PI | 533344 | USD60-80 |
| VMPA14-M1H-B-PI | 573719 | USD60-80 |
| VMPA2-M1H-B-PI | 537954 | USD60-80 |
| VMPA1-M1H-G-PI | 533345 | USD60-80 |
| VMPA14-M1H-G-PI | 573721 | USD60-80 |
| VMPA2-M1H-G-PI | 537955 | USD60-80 |
| VMPA1-M1H-E-PI | 533346 | USD60-80 |
| VMPA14-M1H-E-PI | 573720 | USD60-80 |
| VMPA2-M1H-E-PI | 537956 | USD60-80 |
