Double Acting FESTO ISO Cylinder DNC-63-200-PPV-A 163408 GTIN4052568134297

Double Acting FESTO ISO Cylinder DNC-63-200-PPV-A 163408 GTIN4052568134297

  • Double Acting FESTO ISO Cylinder DNC-63-200-PPV-A 163408 GTIN4052568134297
  • Double Acting FESTO ISO Cylinder DNC-63-200-PPV-A 163408 GTIN4052568134297
Double Acting FESTO ISO Cylinder DNC-63-200-PPV-A 163408 GTIN4052568134297
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: DNC-63-200-PPV-A
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD60-80
Packaging Details: plastic bag, carton,OPP bag
Delivery Time: 7-10working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 50 pcs per month
Contact Now
Detailed Product Description
Brand: FESTO Part No: 163408
Type: DNC-63-200-PPV-A Stroke: 200 Mm
Piston Diameter: 63 Mm Conforms To Standard: ISO 15552
High Light:

Pneumatic ISO Cylinder

,

163408 Pneumatic Air Cylinders

,

Double Acting ISO Cylinder

FESTO ISO cylinder DNC-63-200-PPV-A 163408 GTIN4052568134297

About product

1.Wide range of variants for customised applications.

2.Comprehensive range of mounting accessories for just about every type of installation.

3.ISO 15552 (ISO 6431, VDMA 24562).



Advantage

1.An extensive range of accessories enables the cylinder to be installed virtually anywhere.

2.The widest range of variants on the market offers the ideal cylinder DNC for any application.

3.The modern, consistent design saves up to 11% more space compared to ordinary standards-based cylinders, providing a significantly more compact system structure.



Technical Data

Stroke 200 mm
Piston diameter 63 mm
Piston rod thread M16x1.5
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Conforms to standard ISO 15552
Piston-rod end Male thread
Design Piston Piston rod Profile barrel
Position detection Via proximity switch
Symbol 00991235
Variants Piston rod at one end
Operating pressure 0.06 MPa ... 1.2 MPa
Operating pressure 0.6 bar ... 12 bar
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cushioning length 22 mm
Basic weight for 0 mm stroke 1709 g
Additional weight per 10 mm stroke 73 g
Type of mounting Via female thread With accessories
Pneumatic connection G3/8
Note on materials RoHS-compliant
Material cover Die-cast aluminium Coated
Material seals TPE-U(PU)
Material piston rod High-alloy steel
Material cylinder barrel Wrought aluminium alloy Smooth anodised



Product picture

Double Acting FESTO ISO Cylinder DNC-63-200-PPV-A 163408 GTIN4052568134297



Quality Standards
The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount, but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance, according to the original quality standards, during warranty with product problems, need confirmation testing by the manufacturer, the supplier to be solved, the demand side due to storage, use, poor maintenance caused by lower-quality product, and not raise objections.





There are so many models . Hurry to call me!
