Double acting Festo Compact Cylinder DPDM-16-40-PA 4833191 GTIN4052568293062

Double acting Festo Compact Cylinder DPDM-16-40-PA 4833191 GTIN4052568293062

  • Double acting Festo Compact Cylinder DPDM-16-40-PA 4833191 GTIN4052568293062
  • Double acting Festo Compact Cylinder DPDM-16-40-PA 4833191 GTIN4052568293062
Double acting Festo Compact Cylinder DPDM-16-40-PA 4833191 GTIN4052568293062
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: DPDM-16-40-PA
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD100-150
Packaging Details: Plastic bag, Carton
Delivery Time: 5-7working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 500 pcs per month
Contact Now
Detailed Product Description
Type: DPDM-16-40-PA Part No: 4833191
Brand: FESTO Stroke: 40 Mm
Piston Diameter: 16 Mm Mode Of Operation: Double-acting
Highlight:

4833191 Festo Compact Cylinder

,

Double Acting Festo Compact Cylinder

,

M5 Compact Pneumatic Cylinder

FESTO Compact cylinder DPDM-16-40-PA 4833191 GTIN4052568293062

About product

1.All mounting interfaces of the compact cylinder DPDM are compatible with those of the compact cylinder DMM.

2.Compared to the DMM, however, the DPDM is noticeably shorter, giving a lower product weight for the same functionality.

3.Mounting using through-hole and female thread.

4.Compact design.

5.Piston rod variants.



Technical Data

Stroke 40 mm
Piston diameter 16 mm
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Mode of operation Double-acting
Design Piston Piston rod Profile barrel
Position detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Operating pressure 0.15 MPa ... 0.8 MPa
Operating pressure 1.5 bar ... 8 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B2-L
Ambient temperature -10°C-80°C
Basic weight for 0 mm stroke 66 g
Additional weight per 10 mm stroke 13 g
Type of mounting Either: With through-hole Via female thread
Pneumatic connection M5
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy
Material seals TPE-U(PU)
Material housing Anodised wrought aluminium alloy
Material piston rod High-alloy stainless steel



Application example

Double acting Festo Compact Cylinder DPDM-16-40-PA 4833191 GTIN4052568293062

There are many models. Please hurry to me!
