| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | FRC-1/2-D-MIDI |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD100-120 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 500 pcs per month |
| Type: | FRC-1/2-D-MIDI | Part No: | 159590 |
|---|---|---|---|
| Brand: | FESTO | Weight: | 1440 G |
| Material Bowl: | PC | Material Housing: | Die-cast Zinc |
| High Light: | 159590 Service Unit,Die Cast Zinc Festo Service Unit,159590 Pneumatic System Components |
||
About product
Filter, regulator and lubricator functions in a single unit
High flow rate and highly efficient at removing contaminants
Good regulation characteristics with minimal pressure hysteresis
Setting values are secured by latching the rotary knob
Technical Data
| Size | Midi |
| Series | D |
| Actuator lock | Rotary knob with detent |
| Condensate drain | Manually rotating |
| Max. condensate volume | 43 ml |
| Bowl guard | Metal bowl guard |
| Symbol | 00991549 |
| Pressure gauge (ANALOG) or Pressure display (DIGITAL) | With pressure gauge |
| Operating pressure | 1 bar ... 16 bar |
| Pressure regulation range | 0.5 bar ... 12 bar |
| Max. pressure hysteresis | 0.2 bar |
| Standard nominal flow rate | 2600 l/min |
| Operating medium | Compressed air to ISO 8573-1:2010 [-:9:-] Inert gases |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Air purity class at output | Compressed air to ISO 8573-1:2010 [7:8:-] Inert gases |
| Media temperature | -10°C-60°C |
| Ambient temperature | -10°C-60°C |
| Product weight | 1440 g |
| Type of mounting | In-line installation With accessories |
| Pneumatic connection, port 1 | G1/2 |
| Pneumatic connection, port 2 | G1/2 |
| Note on materials | RoHS-compliant |
| Material housing | Die-cast zinc |
| Material bowl | PC |
Sectional view
