DFM-32-50-P-A-GF Pneumatic Air Cylinders Guided Drive 170858 GTIN4052568013226

DFM-32-50-P-A-GF Pneumatic Air Cylinders Guided Drive 170858 GTIN4052568013226

  • DFM-32-50-P-A-GF Pneumatic Air Cylinders Guided Drive 170858 GTIN4052568013226
  • DFM-32-50-P-A-GF Pneumatic Air Cylinders Guided Drive 170858 GTIN4052568013226
  • DFM-32-50-P-A-GF Pneumatic Air Cylinders Guided Drive 170858 GTIN4052568013226
DFM-32-50-P-A-GF Pneumatic Air Cylinders Guided Drive 170858 GTIN4052568013226
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: DFM-32-50-P-A-GF
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD120-150
Packaging Details: Plastic bag, Carton
Delivery Time: 7-10working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 50 pcs per month
Contact Now
Detailed Product Description
Type: DFM-32-50-P-A-GF Part No: 170858
Brand: FESTO GTIN: 4052568013226
Pneumatic Connection: G1/8 Material Housing: Wrought Aluminium Alloy
Highlight:

DFM-32-50-P-A-GF Pneumatic Air Cylinders

,

170858 Pneumatic Air Cylinders

,

Wrought Aluminium Alloy Pneumatic Cylinder

FESTO Guided drive DFM-32-50-P-A-GF 170858 GTIN4052568013226 Pneumatic Air Cylinders

About Product

1.Excellent protection against torsion, high resistance to torques and transverse loads.

2.Guide rods with yoke.

3.Elastic cushioning rings/plates at both ends.

4.Via proximity switch.

5.Guide rod with yoke/with plain-bearing or ball bearing guide.



Technical Data

Stroke 50 mm
Piston diameter 32 mm
Operating mode, drive unit Yoke
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Guide Plain-bearing guide
Design Guidance
Position detection Via proximity switch
Symbol 00991737
Max. speed 0.8 m/s
Mode of operation Double-acting
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20°C-80°C
Product weight 2254 g
Pneumatic connection G1/8
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy
Material seals NBR
Material housing Wrought aluminium alloy
Material piston rod High-alloy stainless steel



Other size as follow

Type Order no Weight(g) Price
DFM-32-20-P-A-GF 170854 1793 USD120-150
DFM-32-25-P-A-GF 170855 1858 USD120-150
DFM-32-30-P-A-GF 170856 1937 USD120-150
DFM-32-40-P-A-GF 170857 2095 USD120-150
DFM-32-50-P-A-GF 170858 2254 USD120-150
DFM-32-80-P-A-GF 170859 2808 USD120-150
DFM-32-100-P-A-GF 170860 3111 USD120-150
DFM-32-125-P-A-GF 170861 3595 USD120-150
DFM-32-160-P-A-GF 170862 4149 USD120-150
DFM-32-200-P-A-GF 170863 4781 USD120-150



Impact mass m as a function of the impact velocity v

DFM-32-50-P-A-GF Pneumatic Air Cylinders Guided Drive 170858 GTIN4052568013226

A wide range of products with excellent prices. Please hurry to me!
