Place of Origin: | China |
Brand Name: | FESTO |
Model Number: | DRRD-16-180-FH-PA-SG |
Minimum Order Quantity: | 1pc |
---|---|
Price: | EXW USD500-600 |
Packaging Details: | Plastic bag, Carton |
Delivery Time: | 7-10working days |
Payment Terms: | T/T, Western Union, Paypal |
Supply Ability: | 300 pcs per month |
Part No: | 574399 | Brand: | FESTO |
---|---|---|---|
Type: | DRRD-16-180-FH-PA-SG | Size: | 16 |
Note On Materials: | RoHS-compliant | Material Seals: | NBR TPE-U(PU) |
High Light: | Festo Semi Rotary Drive,TPE-U Semi Rotary Drive,Anodised Festo Rotary Drive |
About product
1.Twin-piston drive, power transmission via rack and pinion principle.
2.Extremely accurate in the end positions.
3.Very high load bearing capacity.
Technical Data
Size | 16 |
Swivel angle | 180 deg |
Mounting position | optional |
Design | Rack and pinion |
Position detection | Via proximity switch |
Symbol | 00991265 |
Mode of operation | Double-acting |
LABS (PWIS) conformity | VDMA24364 zone III |
Ambient temperature | -10°C-60°C |
Pneumatic connection | M5 |
Note on materials | RoHS-compliant |
Material drive shaft | Tempered steel |
Material cover | Wrought aluminium alloy Anodised |
Material seals | NBR TPE-U(PU) |
Material housing | Wrought aluminium alloy Smooth anodised |
System components and accessories
