4.2mm Push In Pneumatic Tube Fittings QS-G1/4-6-I 186108 4052568039202

Product Details:

Place of Origin:	China
Brand Name:	FESTO
Model Number:	QS-G1/4-6-I

Payment & Shipping Terms:

Minimum Order Quantity:	10 PCS
Price:	EXW USD2-5
Packaging Details:	carton，OPP bag
Delivery Time:	7-10 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Nominal Size:	4.2 Mm	Order No:	186108
Brand:	FESTO	GTIN:	4052568039202
Specifications:	QS-G1/4-6-I	Weight:	13g
Port 1:	Male Thread G1/4	Port 2:	For Tubing Outside Diameter Of 6 Mm
High Light:	QS-G1/4-6-I Push In Fitting , 4.2mm Pneumatic Tube Fittings , Male Thread Pneumatic Tube Fittings

FESTO,Push-in fitting,QS-G1/4-6-I,186108,GTIN: 4052568039202,Pneumatic Tube Fittings

Name: 4.2mm Push In Pneumatic Tube Fittings QS-G1/4-6-I 186108 4052568039202
Brand: FESTO
SKU: QS-G1/4-6-I
Price: 2 USD
Availability: InStock
Rating: 4.5 (178 reviews)

Nominal size:4.2 mm
Order no:186108
Brand:FESTO
GTIN: 4052568039202
Specifications:QS-G1/4-6-I
Weight:13g
Pneumatic connection, port 1:Male thread G1/4
Pneumatic connection, port 2:For tubing outside diameter of 6 mm

About product
The pipe connector has a series of advantages, such as advanced structure, good performance, convenient use, no welding, no need for pipe expanding, etc. Therefore, the pipe connector has been widely used in various mechanical hydraulic and pneumatic systems.

Advantage
1.Simple plug and play.
2.Reliable connection.
3.Connector can be calibrated after assembly.

Product detial as follow

Feature	Value
Size	Standard
Nominal size	4.2 mm
Type of seal on screw-in stud	Sealing ring
Mounting position	optional
Size of pack	10
Design	Push-pull principle
Operating pressure complete temperature range	-0.95 bar ... 6 bar
Temperature-dependent operating pressure	-0.95 bar ... 14 bar
Note on operating and pilot medium	Lubricated operation possible
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-10 °C ... 80 °C
Nominal torque	9 Nm
Tolerance for nominal tightening torque	± 20%
Product weight	13g
Pneumatic connection, port 1	Male thread G1/4
Pneumatic connection, port 2	For tubing outside diameter of 6 mm
Colour of release ring	Blue
Note on materials	RoHS-compliant
Material housing	Brass Nickel-plated
Material release ring	POM
Material tubing seal	NBR
Material tubing clamp component	High-alloy stainless steel

Another Specifications as follow

Specifications	Order	GTIN	Weight(g)	EXW Price
QS-G1/4-6-I	186108	4052568039202	13	USD2-5
QS-G1/4-8-I	186110	4052568039219	14	USD2-5
QS-G1/4-10-I	186112	4052568014650	20	USD2-5
QS-G3/8-8-I	186111	4052568039226	20	USD2-5
QS-G3/8-10-I	186113	4052568039233	22	USD2-5
QS-G3/8-12-I	186114	4052568039240	34	USD2-5
QS-G1/2-12-I	186115	4052568039257	33	USD2-5

Push-in fitting QS
Male thread with external hex
4.2mm Push In Pneumatic Tube Fittings QS-G1/4-6-I 186108 4052568039202

Relation between working pressure and temperature

Attention
1.Do not use it for any purpose other than quick fluid coupling.
2.Do not use for fluids other than applicable fluids.
3.Please do not connect with the quick fluid connector made by other companies.
4.Do not exceed the maximum operating pressure.
5.Do not use outside the operating temperature range to prevent wear or leakage of sealing materials.
6.Do not strike, bend or stretch artificially to prevent damage.
7.Do not use it in places mixed with metal powder or sand dust to prevent poor work or leakage.
8.If sundries are attached, it will cause poor operation or leakage.

There are many specifications of connectors, price and delivery time. Welcome to inquire.
