| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | DFM-10-10-P-A-GF |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD40-50 |
| Packaging Details: | Plastic bag, Carton，OPP bag |
| Delivery Time: | 10-15working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 80 pcs per month |
| Brand: | FESTO | Part No: | 4154769 |
|---|---|---|---|
| Type: | DFM-10-10-P-A-GF | GTIN: | 4052568418052 |
| Max. Speed: | 1.7 M/s | Mode Of Operation: | Double-acting |
| High Light: | 4154769 Cylinders Guided Drive,Guided Drive DFM-10-10-P-A-GF,1.7m/s Pneumatic Air Cylinders |
||
Advantage
1.Minimal space requirement.
2.Minimal mounting time.
3.Choice of compressed air supply ports.
4.Wide range of mounting options.
5.Good protection against torsion.
Technical Data
| Stroke | 10 mm |
| Piston diameter | 10 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Guide | Plain-bearing guide |
| Design | Guidance |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Max. speed | 1.7 m/s |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-60°C |
| Product weight | 45.5 g |
| Pneumatic connection | M3 |
| Note on materials | RoHS-compliant |
| Material cover | High-alloy stainless steel |
| Material seals | NBR |
| Material dynamic seals | HNBR |
| Material end plate | Anodised wrought aluminium alloy |
| Material guide rod | High-alloy stainless steel |
| Material housing | Anodised wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Other size as follow
| Type | Order no | Weight(g) | Price |
| DFM-10-5-P-A-GF | 4154768 | 38 | USD40-50 |
| DFM-10-10-P-A-GF | 4154769 | 45.5 | USD40-50 |
| DFM-10-15-P-A-GF | 4154770 | 53.5 | USD40-50 |
| DFM-10-20-P-A-GF | 4154799 | 60.5 | USD40-50 |
Use in conveyor systems
Festo Core Range Solves the majority of your automation tasks.With the Festo Core Range, we have selected the most important products and functions from our broad product catalogue, and added the quickest delivery.
A wide range of products with excellent prices. Please hurry to me!
