2V130-15 1/2" Pneumatic Solenoid Valve 24vdc DN15 Flow Control

AIRTAC 2V Series 2V130-15 1/2" DC24V DN15 Flow control Solenoid valve

1. Before installing, be sure the valve hasn't been damaged via transportation.

2. The coil must be pure vertical, the inlet and outlet on body must be horizontal. it's
suggested to use the

medium lubricated by 40μm filter element. Be aware of the flow
direction and port size.

3. Please notice whether the installation condition accords with technical requirements (such
as

"voltage",factuation frequency", "working pressure" and "scope of application
temperature"), then the

equipment can be installed and used.

4. Take measure to avoid vibration and frozen.

5. Before using the ftings and tubes make sure they are clean. When connecting tfitings,
be sure the PTFE

Thread Seal Tape is used correctly.

6. To keep the dust away, Default paragraph font;Never forget to install dirt-proof boot in air
intake and outlet

during dismounting.

2V025 series

1. Direct acting and normally closed type 2/2 way solenoid valve. Its high sensitivity llows it
to change direction

quickly.

2. The structure is small and compact.

3. The valve body is made of brass which is heat resistance and the coil conforms to Class B
casification. The

seals are made of fluorine rubber (MITON) which is suitable for several
types of working medium.
2V130 and
250 series

1. This 2/2 way diaphragm piloted solenoid valve has low energy consumption and large air
flow .

2. The starting pressure is low and the operational differential pressure is < 0.05MPa.

3. The valve body is made of brass which is heat resistance and the coil conforms to Class B
clasification. The

seals are made of NBR.

After-sales clause:
One year quality guarantee Policy
We will check the goods quality before shipment. If there are some unexpected problems
happen, we hope to solve the problems with buyer through friendly in the following ways:
1, If it is quality problem, buyer can submit argue within 15days after receiving the goods,
buyer must provide photos or video and other evidence to seller for identify.
2, Man-made damaged, buyers take full responsibility.
3, Product quality processing program:
1) The buyer return the products for bad quality reasons for one year (not included those
damages coursed by shipping or Man-made damaged ). A 15% restocking fee is
assessed for any products returned in "used" condition. And then we will send a new
product to buyer and pay for the resend shipping cost.
2) If the goods (total price including shipping is less than 10USD) has quality problems, we
will resend a new product in buyer next order; if buyer don't plan to make a new order in
the near term, buyer can pay the resend shipping cost and ask to resend a new product. If
there is an issue with the products, please contact us– we will solve it as soon as we get
your email.
