2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve

2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve

  • 2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve
  • 2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve
  • 2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve
  • 2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve
2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve
Product Details:
Place of Origin: China
Brand Name: Techno
Certification: CE
Model Number: MOV-02 MOV-01 MOV-03
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiation
Packaging Details: Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement
Delivery Time: within 1-30 working days after payment
Payment Terms: T/T , Western Union
Supply Ability: 1000 pcs
Contact Now
Detailed Product Description
Model Code: MOV-02 MOV-01 MOV-03 Body Material: Aluminum Alloy
Name: Mechanical Valve Fluid Temperature: 0~60℃
Color: Red/Black
High Light:

foot pedal valve

,

pneumatic mechanical valve

2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve



Features
Roller Proximity Air Valve with Momentary Roller Lever: MOV-02
The MOV-02 is a manual pneumatic directional valve with a three-way operation & two ports (P = Pressure, A = Outlet). The exhaust port (EA) is internal and shown on the pneumatic diagram for clarity. Three-way, two-position valves are generally used to fully extend a single acting (spring return) cylinder, or in applications with similar operation.

Characteristics:
1) The MOV series mechanical valve is controlled by human or machine, to switch the direction of air flow.
2) The material of valve body: Aluminum alloy.
3) Different button types are available, like selective knob,lock button, plat round and roller.
4) Different thread types can be offered according to customers' requirements, e.g.: PT, NPT etc.

Specification


ModelMOV-01MOV-02MOV-03MOV-04
Valve typeTwo positions two ways
Applicable mediumCompressed air
Working pressure0~0.8 MPa
Temperature range0℃~60℃
Port sizeG1/8

MOV-02
Operation3 way, 2 port, 2 position Momentary Roller Lever
TypeHand Operated Directional Air Valve
Port size1/8" NPT
Operating pressure0 to 116 PSI
Operating Temperature14 to 140℉(-10~60℃)
ActionDirect Acting
Flow Coefficient(Cv)0.67
Working Medium40 Micron Filtered Air or Inert Gas
Body MaterialAnodized Aluminum
Seal MaterialNBR(Buna N)
LubricationNot Required


 2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve2 Port 2 Position Mechanical Valve MOV-02 MOV-01 MOV-03 Roller Type MOV Series Mechanical Valve
