1/4" Series Solenoid Valve 3 / 2 Way Aluminum Alloy AC220V

Product Details:

Place of Origin:	China
Brand Name:	AIRTAC
Certification:	ISO Standand
Model Number:	3V308NOB

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	Negotiation
Packaging Details:	Plastic bags, boxes, cartons, Pallets or As customer's requirement
Delivery Time:	7 working Days
Payment Terms:	T/T, Western Union, MoneyGram Paypal
Supply Ability:	1000 PCS Per Week

Contact Now

Detailed Product Description

MODEL:	3V308	Fluid:	Air (to Be Filtered 40 μm Filter Element)
Port Size:	1/4"	Temperature :	-20-70℃
Marterial Of Body:	Aluminum Alloy	Voltage:	AC220V
Highlight:	Alu Alloy Pneumatic Solenoid Valves , 3/2 Way Pneumatic Solenoid Valves , 3 Port 2 Position Solenoid Valve

AIRTAC 3V308 1/4" series Solenoid valve 3/2 way Aluminum alloy AC220V

3V3 SERIES

We have various models. No matter what model you need, please feel free to contact me.

If you have any questions about the price, you can contact me at any time.

3V3 SERIES DETAILES:

MODEL		3V308
Fluid		air (to be filtered 40 μm filter element)
Acting		direct acting
port size		1/4"
Orifice size		11MM² (Cv=0.62)
VALVE TYPE		3 port 2 positions
Lubrication		Not required
Operating pressure	common	0-0.8MPa(0-114psi)
	vacuum	-102.2KPa-0.1Mpa (-1.45-14.2psi)
Proof pressure		1.2MPa(175psi)
Marterial of body		aluminum alloy
Temperature		-20-70℃

COIL SPECIFICATION:

MODEL	Specification
standard voltage	AC220V	AC110V	AC24V	DC24V	DC12V
Scope of voltage	AC+_15% DC+_10%
Power consumption	AC:10VA DC:6.5W
Protection	IP65(DIN40050)
Temperature classification	B CLASS
Electrical enrty	Terminal Grommet
Activating time	0.05 sec and below
Max. frequency	Note 10 cycle/sec
