19237 GTIN4052568003357 Pneumatic Air Cylinders DSNU-20-50-PPV-A ISO

19237 GTIN4052568003357 Pneumatic Air Cylinders DSNU-20-50-PPV-A ISO

  • 19237 GTIN4052568003357 Pneumatic Air Cylinders DSNU-20-50-PPV-A ISO
  • 19237 GTIN4052568003357 Pneumatic Air Cylinders DSNU-20-50-PPV-A ISO
  • 19237 GTIN4052568003357 Pneumatic Air Cylinders DSNU-20-50-PPV-A ISO
19237 GTIN4052568003357 Pneumatic Air Cylinders DSNU-20-50-PPV-A ISO
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: DSNU-20-50-PPV-A
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD25-35
Packaging Details: plastic bag, carton，OPP bag
Delivery Time: 7-10 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 100 pcs per month
Contact Now
Detailed Product Description
Brand: FESTO Type: DSNU-20-50-PPV-A
Part No: 19237 GTIN: 4052568003357
Highlight:

Pneumatic Cushioning Air Cylinder

,

19237 Pneumatic Air Cylinders

,

Double Acting Compact Cylinder

FESTO ISO cylinder DSNU-20-50-PPV-A 19237 GTIN4052568003357 Pneumatic Air Cylinders

About product

1.Pneumatic cushioning, adjustable at both ends.

2.The ultra durable cylinder based on ISO6432 has a self-adjusting end position buffer and a large number of accessories.

3.High operating power and long service life.



Technical Data

Stroke 50 mm
Piston diameter 20 mm
Piston rod thread M8
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Conforms to standard CETOP RP 52 P ISO 6432
Piston-rod end Male thread
Design Piston Piston rod Cylinder barrel
Position detection Via proximity switch
Symbol 00991235
Variants Piston rod at one end
Mode of operation Double-acting
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 6 according to ISO 14644-1
Ambient temperatur -20°C-80°C
Cushioning length 15 mm
Basic weight for 0 mm stroke 186.8 g
Additional weight per 10 mm stroke 7.2 g
Type of mounting With accessories
Pneumatic connection G1/8
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy Colourless anodised
Material seals NBR TPE-U(PU)
Material piston rod High-alloy stainless steel
Material cylinder barrel High-alloy stainless steel



Another stroke as follow

Type Order no GTIN Price
DSNU-20-10-PPV-A 1908289 4052568108700 USD40-50
DSNU-20-15-PPV-A 1908290 4052568108717 USD40-50
DSNU-20-20-PPV-A 1908291 4052568108724 USD40-50
DSNU-20-25-PPV-A 33974 4052568009755 USD40-50
DSNU-20-30-PPV-A 1908292 4052568108731 USD40-50
DSNU-20-35-PPV-A 1908293 4052568108748 USD40-50
DSNU-20-40-PPV-A 19236 4052568003340 USD40-50
DSNU-20-50-PPV-A 19237 4052568003357 USD40-50
DSNU-20-60-PPV-A 1908294 4052568108755 USD40-50
DSNU-20-70-PPV-A 1908295 4052568108762 USD40-50
DSNU-20-80-PPV-A 19238 4052568003364 USD40-50
DSNU-20-100-PPV-A 19239 4052568067113 USD40-50
DSNU-20-125-PPV-A 19240 4052568003371 USD40-50
DSNU-20-150-PPV-A 1908296 4052568249120 USD40-50
DSNU-20-160-PPV-A 19241 4052568003388 USD40-50
DSNU-20-200-PPV-A 19242 4052568003395 USD40-50
DSNU-20-250-PPV-A 19243 4052568003401 USD40-50
DSNU-20-300-PPV-A 19244 4052568003418 USD40-50
DSNU-20-320-PPV-A 34720 4052568010065 USD40-50



Delivery

1. If the products we have in store, we will send it out ASAP after payment.

2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.

3. Also we can send by your delivery acount if you want.

4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.



There are so many type ,please call me immediately!
