1908307 Pneumatic Air Cylinders FESTO ISO Cylinder DSNU-25-30-P-A

1908307 Pneumatic Air Cylinders FESTO ISO Cylinder DSNU-25-30-P-A

  • 1908307 Pneumatic Air Cylinders FESTO ISO Cylinder DSNU-25-30-P-A
  • 1908307 Pneumatic Air Cylinders FESTO ISO Cylinder DSNU-25-30-P-A
1908307 Pneumatic Air Cylinders FESTO ISO Cylinder DSNU-25-30-P-A
Product Details:
Brand Name: FESTO
Model Number: DSNU-25-30-P-A
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD40-50
Packaging Details: plastic bag, carton，OPP bag
Delivery Time: 7-10 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000 pcs per month
Contact Now
Detailed Product Description
Brand: FESTO Type: DSNU-25-30-P-A
Part No: 1908307 Stroke: 30 Mm
Conforms To Standard: CETOP RP 52 P ISO 6432 Cleanroom Class: Class 6 According To ISO 14644-1
Highlight:

1908307 Pneumatic Air Cylinders

,

DSNU-25-30-P-A

,

ISO Festo Pneumatic Cylinder

FESTO ISO cylinder DSNU-25-30-P-A 1908307 Pneumatic Air Cylinders

About product

Low impact energies

No adjustment required

Saves time

Mounting position:optional

Conforms to standard:CETOP RP 52 P ISO 6432



Technical Data

Stroke 30 mm
Piston diameter 25 mm
Piston rod thread M10x1.25
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Conforms to standard CETOP RP 52 P ISO 6432
Piston-rod end Male thread
Design Piston Piston rod Cylinder barrel
Symbol 00991217
Variants Piston rod at one end
Mode of operation Double-acting
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Cleanroom class Class 6 according to ISO 14644-1
Ambient temperature -20°C-80°C
Basic weight for 0 mm stroke 238 g
Additional weight per 10 mm stroke 11 g
Pneumatic connection G1/8
Note on materials RoHS-compliant
Material cover Wrought aluminium alloy Colourless anodised
Material seals NBR TPE-U(PU)
Material piston rod High-alloy stainless steel
Material cylinder barrel High-alloy stainless steel



There are so many models ,please contact with me.



Product range overview

1908307 Pneumatic Air Cylinders FESTO ISO Cylinder DSNU-25-30-P-A
