| Brand Name: | FESTO |
| Model Number: | ADVUL-32-60-P-A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD50-80 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 8-12working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1200 pcs per month |
| Type: | ADVUL-32-60-P-A | Brand: | FESTO |
|---|---|---|---|
| Part No: | 156882 | Mounting Position: | Optional |
| Pneumatic Connection: | G1/8 | Material Cylinder Barrel: | Wrought Aluminium Alloy |
| High Light: | 156882 Pneumatic Air Cylinders,Wrought Aluminium Alloy Pneumatic Compact Cylinder |
||
About product
Mounting position:optional
Protection against torque/guide:Guide rod with yoke
Pneumatic connection:G1/8
Material cylinder barrel:Wrought aluminium alloy
Material piston rod:High-alloy stainless steel
Technical Data
| Stroke | 60mm |
| Piston diameter | 32 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Design | Piston Piston rod |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Variants | Piston rod at one end |
| Protection against torque/guide | Guide rod with yoke |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Pneumatic connection | G1/8 |
| Material collar screws | Galvanised steel |
| Material cover | Wrought aluminium alloy |
| Material dynamic seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy stainless steel |
| Material cylinder barrel | Wrought aluminium alloy |
Dimensions – Basic cylinders
Attention
1.Before you endorse the parcel, please do open the package, and check out whether the items are damaged during the shipping process.
If so, please do refuse to sign for the parcel, the courier will send back the package to our company. Otherwise we are not responsible for this...
2.Any order is welcome. we will give discounts and combined shipping costs for you if you order more or mix order. If you have any questions.
please feel free to contact us.
There are so many models . Please contact with me!
