156054 Festo Compact Cylinder Pneumatic Air Cylinders ADVU-32-A-P-A-S2

156054 Festo Compact Cylinder Pneumatic Air Cylinders ADVU-32-A-P-A-S2

  • 156054 Festo Compact Cylinder Pneumatic Air Cylinders ADVU-32-A-P-A-S2
  • 156054 Festo Compact Cylinder Pneumatic Air Cylinders ADVU-32-A-P-A-S2
156054 Festo Compact Cylinder Pneumatic Air Cylinders ADVU-32-A-P-A-S2
Product Details:
Place of Origin: China
Brand Name: FESTO
Model Number: ADVU-32- -A-P-A-S2
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: EXW USD150-180
Packaging Details: Plastic bag, Carton
Delivery Time: 7-10working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 20 pcs per month
Contact Now
Detailed Product Description
Type: ADVU-32- -A-P-A-S2 Part No: 156054
Brand: FESTO Symbol: '00991219
Piston Diameter: 32 Mm Pneumatic Connection: G1/8
Highlight:

Double Acting Festo Compact Cylinder

,

156054 Compact Pneumatic Cylinder

,

G1/8 Compact Pneumatic Cylinder

FESTO Compact cylinder ADVU-32- -A-P-A-S2 156054 Pneumatic Air Cylinders

About product

Piston rod withmale thread

50% less installation space than comparable standards-based cylinders to ISO 15552

Wide range of variants for customised applications



Technical Data

Stroke 1 mm ... 300 mm
Piston diameter 32 mm
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Mode of operation Double-acting
Piston-rod end Male thread
Design Piston Piston rod
Position detection Via proximity switch
Symbol 00991219
Variants Through piston rod
Operating pressure 0.1 MPa ... 1 MPa
Operating pressure 1 bar ... 10 bar
Operating pressure 14.5 psi ... 145 psi
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Impact energy in end positions 0.4 J
Type of mounting Either: With through-hole With accessories
Pneumatic connection G1/8
Material collar screws Galvanised steel
Material cover Wrought aluminium alloy
Material dynamic seals NBR TPE-U(PU)
Material piston rod High-alloy stainless steel
Material cylinder barrel Wrought aluminium alloy



Product picture

156054 Festo Compact Cylinder Pneumatic Air Cylinders ADVU-32-A-P-A-S2

A wide range of products with excellent prices. Please hurry to me!
