| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | QS-1/8-4-I |
| Minimum Order Quantity: | 10 PCS |
|---|---|
| Price: | EXW USD2-5 |
| Packaging Details: | carton，OPP bag |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000 pcs per week |
| Nominal Size: | 2.6 Mm | Order No: | 153012 |
|---|---|---|---|
| Brand: | FESTO | GTIN: | 4052568031190 |
| Specifications: | QS-1/8-4-I | Weight: | 6.6g |
| High Light: | 153012 Pneumatic Tube Fittings,QS-1/8-4-I Push In Fitting,Alloy Pneumatic Tube Fittings |
||
Nominal size:2.6 mm
Order no:153012
Brand:FESTO
GTIN: 4052568031190
Specifications:QS-1/8-4-I
Weight:6.6g
All R threads are coated with sealing material layer,This coating replaces the traditional seal circle,Simply screw in the R thread by hand,And tighten it with a wrench for one or two turns that will do,Connectors can be installed repeatedly at most Five times,When screwing in the R thread several times, you must ensure that Wear particles in the sealing material coating Not entering the compressed air system.
The pipe connector has a series of advantages, such as advanced structure, good performance, convenient use, no welding, no need for pipe expanding, etc. Therefore, the pipe connector has been widely used in various mechanical hydraulic and pneumatic systems.
product detail as follows
| Feature | Value |
| Size | Standard |
| Nominal size | 2.6mm |
| Type of seal on screw-in stud | Coating |
| Mounting position | optional |
| Size of pack | 10 |
| Design | Push-pull principle |
| Operating pressure complete temperature range | -0.95 bar ... 6 bar |
| Temperature-dependent operating pressure | -0.95 bar ... 14 bar |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10 °C ... 80 °C |
| Product weight | 6.6g |
| Pneumatic connection, port 1 | Male thread R1/8 |
| Pneumatic connection, port 2 | For tubing outside diameter of 4 mm |
| Colour of release ring | Blue |
| Note on materials | RoHS-compliant |
| Material housing | Brass Nickel-plated |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
Another Specifications
| Specifications | Order NO | GTIN | Weight(g) | EXW Price | Nominal size(mm) |
| QS-1/8-4-I | 153012 | 4052568031190 | 6.6 | USD2-5 | 2.60 |
| QS-1/8-4 | 153001 | 4052568010928 | 7.4 | USD2-5 | 3.00 |
| QS-1/8-6-I | 153013 | 4052568031206 | 7.6 | USD2-5 | 4.20 |
| QS-1/8-6 | 153002 | 4052568010935 | 8.2 | USD2-5 | 5.00 |
About thread R
1.Self sealing thread.
2.Sealing by coated threads.
3.No additional sealing surfaces are required.
4.Because there is no need to reserve space for the sealing surface, the installation size is smaller.
5.Reusable up to five times.
Relation between working pressure p and temperature t
