| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | SIEN-M18NB-PS-K-L |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | USD50-60 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 120 pcs per week |
| Part No: | 150426 | Type: | SIEN-M18NB-PS-K-L |
|---|---|---|---|
| GTIN: | 4052568069360 | Brand: | FESTO |
| Conforms To Standard: | EN 60947-5-2 | Switching Output: | PNP |
| High Light: | 150426 Proximity Sensor,Pneumatic System Proximity Sensor,PNP Proximity Switch |
||
About product
1.With standard switching distance.
2.For DC voltage.
3.Round design.
4.Switching output:PNP.
5.Switching element function:N/O contact.
6.Type of installation:Not flush P.
7.Corrosion-resistant .
8.Polyamide housing.
Product Technical Data
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991702 |
| Approval | RCM trademark c UL us listed (OL) |
| CE mark (see declaration of conformity) | To EU EMC Directive |
| Note on materials | RoHS-compliant |
| Rated operating distance | 8 mm |
| Assured operating distance | 6.48 mm |
| Repetition accuracy | 0.4 mm |
| Switching output | PNP |
| Switching element function | N/O contact |
| Hysteresis | 0.88 mm |
| Max. switching frequency | 2000 Hz |
| Max. output current | 200 mA |
| Voltage drop | 2 V |
| Short circuit current rating | Pulsed |
| No-load supply current | 10 mA |
| Reverse polarity protection | For all electrical connections |
| Electrical connection | 3-wire Cable |
| Cable length | 2.5 m |
| Material cable sheath | TPE-U(PUR) |
| Size | M18x1 |
| Type of mounting | Via lock nut |
| Tightening torque | 20 Nm |
| Mounting type | Not flush |
| Product weight | 105 g |
| Material housing | Brass PBTP Nickel-plated |
| Switching status indication | Yellow LED |
| Degree of protection | IP67 |
| Immunity to surge | 0.8 kV |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Pollution degree | 3 |
| Additional information for sensor selection | with standard sensing distance |
| Electrical output | PNP |
| Selection of sensor design | Standard |
There are many specifications of connectors, price and delivery time. Welcome to inquire.
