| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | DGC-K-18-480 -PPV-A-GK |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD400-450 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 20 pcs per month |
| Type: | DGC-K-18-480 -PPV-A-GK | Part No: | 1312500 |
|---|---|---|---|
| Brand: | FESTO | Piston Diameter: | 18 Mm |
| Cushioning Length: | 16 Mm | Material Cover: | Die-cast Aluminium |
| High Light: | Linear Drive Pneumatic Air Cylinders,1312500 Festo Linear Drive,Die Cast Aluminium Pneumatic Air Cylinders |
||
About Product
1.Compact design: 30% smaller than basic design DGC-G.
2.Basic drive without guide, for simple drive functions.
3.Low moving dead weight.
4.Without external guide, for simple drive functions.
5.Compact – installation length relative to stroke .
6.Choice of: Standard piston/ Extended piston.
Advantages of the sealing system
1.Long strokes with no restrictions.
2.Virtually no leakage.
3.Fully interchangeable with the linear drive DGP.
4.Easy assembly and installation.
Technical Data
| Stroke | 1 mm ... 3000 mm |
| Piston diameter | 18 mm |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Position detection | Via proximity switch |
| Variants | Supply port at both ends Standard piston Extended piston |
| Mode of operation | Double-acting |
| CE mark (see declaration of conformity) | To EU Explosion Protection Directive (ATEX) |
| CE marking (see declaration of conformity) | To UK EX instructions |
| Explosion protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 22 (ATEX) |
| ATEX category gas | II 2G |
| ATEX category dust | II 3D |
| Explosion ignition protection type for gas | Ex h IIC T4 Gb X |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Suitable for use with food | See supplementary material information |
| Ambient temperature | -10°C-60°C |
| Cushioning length | 16 mm |
| Type of mounting | With accessories |
| Note on materials | RoHS-compliant |
| Material cover | Die-cast aluminium |
| Material seals | NBR TPE-U(PU) |
Product picture
