| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | VUVG-B10-T32C-AZT-F-1T1L |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD50-60 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 200 pcs per month |
| Model: | VUVG-B10-T32C-AZT-F-1T1L | Order No: | 573410 |
|---|---|---|---|
| Brand: | FESTO | Type Of Actuation: | Electric |
| Valve Size: | 10 Mm | Operating Voltage: | 24V DC |
| High Light: | 10 Mm Pneumatic Solenoid Valves,573410 Pneumatic Solenoid Valves,Sub Base Air Operated Solenoid Valve |
||
About product
1.Variants to EU Explosion Protection Directive (ATEX).
2.Sub-base valve, semi in-line valve.
3.For valve terminal VTUG with multi-pin, fieldbus interface.
4.Inscription label holder for labelling.
5.Easy mounting thanks to captive screws and seal .
6.Connection technology easy to change .
Technical Data
| Valve function | 2x3/2-way, monostable, closed |
| Type of actuation | Electric |
| Valve size | 10 mm |
| Standard nominal flow rate | 150 l/min |
| pneumatic working port | Flange |
| Operating voltage | 24V DC |
| Design | Piston gate valve |
| Type of reset | Pneumatic spring |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP65 IP67 |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | External |
| Symbol | 00992905 |
| lap | Positive overlap |
| Signal status display | LED |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 59 g |
| Electrical connection | Via sub-base |
| Type of mounting | On manifold rail |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Wrought aluminium alloy |
Product picture
