Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
Place of Origin: | CHINA JAPAN |
Brand Name: | SMC ,OEM |
Model Number: | MB1B32-100Z MB1B40-100Z MB1B50-75Z MB1B63-125Z MB1B32-125Z MB1B40-125Z MB1B50-100Z MB1B63-150Z MB1B32-150Z MB1B40-150Z MB1B50-125Z MB1B63-175Z MB1B32-175Z MB1B40-175Z MB1B50-150Z MB1B63-225Z |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | 35-225USD |
Packaging Details: | Cartons, Pallets |
Delivery Time: | 2-5 workin days |
Payment Terms: | T/T, Western Union,Paypal, Alipay |
Supply Ability: | 20 Pcs per day |
Fuid: | Compressed Air | Action: | Double Acting, Single Rod |
---|---|---|---|
Maximum Operating Pressure: | 1.0Mpa | Minimum Operating Pressure: | 0.05Mpa |
Proof Pressure (MPa): | 1.5Mpa | Ambient And Fluid Temperature: | Without Auto Switch:-10 To 70°C With Auto Switch: - -10 To 60°C No Freezing |
Piston Speed: | 50 To 1000 Mm/s | Lubrication: | Not Required (Non-lube) |
Cushion: | Air Cushion Or Rubber Bumper | Mounting: | Basic, Axial Foot, Rod Flange, Head Flange Single Clevis, Double Clevis |
How to order:
Specifications:
Bore size [mm] | 32 | 40 | 50 | 63 | 80 | 100 | 125 |
Action | Double acting, Single rod | ||||||
Fluid | Air | ||||||
Proof pressure | 1.5MPa | ||||||
Maximum operating pressure | 1.0 MPa | ||||||
Minimum operating pressure | 0.05 MPa | ||||||
Ambient and fluid temperature | Without auto switch:-10 to 70°C With auto switch: - -10 to 60°C No freezing | ||||||
Lubrication | Not required (Non-lube) | ||||||
Piston speed | 50 to 1000 mm/s | ||||||
Cushion | Air cushion or Rubber bumper | ||||||
Port size (Rc, NPT, G) | 1/8 | 1/4 | 3/8 | 1/2 | |||
Mounting | Basic, Axial foot, Rod flange, Head flange Single clevis, Double clevis |
