QFLJWC-L8 QFLJWC-L15 FANGDA Pneumatic C Series FRL Unit Air Preparation Units
Order Codes:
| Item Code |
Nominal Diameter |
Port Size |
| QFLJWC-L8 |
8mm |
G1/4" |
| QFLJWC-L15 |
15mm |
G1/2" |
Symbol:
Specification:
| Nominal Diameter (mm) |
8 |
15 |
| Working Medium |
Compressed Air |
| Operating Temperature Range (°C) |
-25~+80 (no freezing) |
| Maximum Inlet Pressure (MPa) |
1 |
| Water Separation Efficiency |
≥ 80% |
| Filtration Accuracy (μm) |
40 |
| Pressure Characteristic |
The output flow is stable at the set value. The change in the adjusted output pressure due to variations in the input pressure shall not exceed 0.05 MPa. |
| Flow Characteristics |
Inlet Pressure (MPa) |
Outlet Pressure (MPa) |
Air Flow Rate (at standard state) dm³/min |
| 1.00 |
Nominal Diameter |
8 |
15 |
| 0.25 |
300 |
1090 |
| 0.4 |
370 |
1270 |
| 0.63 |
450 |
1440 |
| Indicates that when the outlet pressure drops by 0.1 MPa, the maximum flow rate is not less than the value above. |
| Oil Mist Flow |
Refers to the air flow rate when the oil level is in the middle of the oil cup and the oil drop rate is about 5 drops/minute. This flow rate is not greater than the value below. |
| Nominal Diameter |
8 |
15 |
| Inlet Pressure |
Oil Mist Flow Rate (at standard state) dm³/min |
| 0.25 |
105 |
170 |
| 0.4 |
130 |
190 |
| 0.63 |
180 |
220 |
| Lubricating Oil Flow Adjustment |
When the input working pressure is 0.4 MPa and the outlet flow rate is at the set value, the oil drop rate should be adjustable within the range of 0 ~ 120 drops/minute. |
| Pressure Adjustment Range (MPa) |
0.05~0.8 |
Dimensions:
| Model |
H1 |
H2 |
A1 |
A2 |
A3 |
L1 |
L2 |
Φ |
M1 |
M |
| QFLJWC-L8 |
182 |
118 |
53 |
22.5 |
55 |
135 |
35 |
Φ4.5 |
M30X1.5 |
G1/4" |
| QFLJWC-L15 |
255 |
154 |
60 |
31 |
78 |
186 |
46 |
Φ5.5 |
M47X1.5 |
G1/2" |
