Name: MVSC-180-4E1 MVSC-180-4E2 MVSC-180-4E2C.P.R Mindman 5/2 way 5/3 way Solenoid Valve Rc1/8
Brand: Airwolf Automation
SKU: MVSC-180-4E1, MVSC-180-4E2, MVSC-180-4E2C, MVSC-180-4E2P, MVSC-180-4E2R
Price: 12.00 USD
Availability: InStock

Home Products Pneumatic Solenoid Valves

MVSC-180-4E1 MVSC-180-4E2 MVSC-180-4E2C.P.R Mindman 5/2 way 5/3 way Solenoid Valve Rc1/8

Product Details:

Place of Origin:	Taiwan, China or China
Brand Name:	Mindman, AIRWOLF or OEM
Certification:	ISO Standand
Model Number:	MVSC-180-4E1, MVSC-180-4E2, MVSC-180-4E2C, MVSC-180-4E2P, MVSC-180-4E2R

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	11-14USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Item Code:	MVSC-180-4E1, MVSC-180-4E2, MVSC-180-4E2C, MVSC-180-4E2P, MVSC-180-4E2R	Material:	Body: Aluminum, Seal: NBR
Operating Pressure:	0.15~0.8 MPa, 0.2~0.7 MPa(4E2C.P.R)	Working Temperature Range:	-5~+50℃
Port Size:	Rc1/8	Position:	5/2 Way, 5/3 Way
Working Medium:	Dry Compressed Air Filtered By 40μm	Operating Voltage:	AC110V, AC220V, DC24V
Highlight:	Mindman 5/2 way solenoid valve Rc1/8 , Pneumatic solenoid valve with warranty , 5/3 way solenoid valve Rc1/8

MVSC-180-4E1 MVSC-180-4E2 MVSC-180-4E2C.P.R Mindman 5/2 way 5/3 way Solenoid Valve Rc1/8

For technical specifications, the MVSC-180 series featured a port size of Rc1/8 and offered different flow rates depending on the model: approximately 817 l/min for the 3/2-way version, 653 l/min for the 5/2-way version, and 490 l/min for the 5/3-way version . The valve's construction included an aluminum body and was rated for an ambient temperature range of -5 to 50 °C (without freezing) . While this specific series is discontinued, it serves as a predecessor to other models in Mindman's portfolio, and its technical details remain relevant for understanding the evolution of compact pneumatic valve design and for maintaining existing equipment.

Order Codes:

Item Code	Port Size	Position	Type
MVSC-180-4E1	Rc 1/8	5/2 way	Single Solenoid
MVSC-180-4E2	Rc 1/8	5/2 way	Double Solenoid
MVSC-180-4E2C	Rc 1/8	5/3 way	Double Solenoid
MVSC-180-4E2P	Rc 1/8	5/3 way	Double Solenoid
MVSC-180-4E2R	Rc 1/8	5/3 way	Double Solenoid

Specification:

Model	3E1	3E2	4E1	4E2	4E2C.P.R
Bore No.	6A
Port size	Rc1/8
No. of port	3		5
No. of position	2				3
Medium	Air
Operating pressure range	0.15~0.8 MPa				0.2~0.7 MPa
Operating pressure (LP)	0~0.8 MPa				0~0.7 MPa
External pilot pressure (LP)	0.15~0.8 MPa				0.2~0.7 MPa
Proof pressure	1 MPa
Effective orifice	15 mm²		12 mm²		9 mm²
Response time	30 ms
Ambient temperature	− 5~+50℃ (No freezing)
Voltage	AC110V, 220V (50/60)Hz, DC24V
Power consumption	AC=3.7/ 3.1VA, DC=3W
Available voltage range	±10%
Insulation class	F class
Weight	120 g	172 g	124 g	176 g	190 g

Dimensions:

MVSC-180-4E1 MVSC-180-4E2 MVSC-180-4E2C.P.R Mindman 5/2 way 5/3 way Solenoid Valve Rc1/8

Quality Standards:

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.

Samples:

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

After-sale service:

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.

Competitive Advantage:

Our product features:	Our Services Guarantee:
1) Competitive price	1) Prompt respond (Reply with 24 hours)
2) Good quality	2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging	3) 1 year warranty
4) Produce according to Customers’ instruction	4) Photos/videos are available during production.
5) None delay shipment	5) Loading inspection, and send loading photos before shipment.
