Mindman MVSE-510-4E1 MVSE-510-4E2 5/2 way Solenoid Valve 1/2"

The Mindman MVSE-510 Series is a robust, direct-piping type solenoid valve designed for high-flow pneumatic applications. Its defining feature is a 51 mm body width, positioning it as a high-capacity model within the MVSE series . It features a PT 1/2 port size​ and is configured as a 5-port, 2-position (5/2) valve​ for controlling double-acting cylinders . Engineered for demanding industrial use, it operates within a pressure range of 2 to 7 kgf/cm² (approximately 0.2 to 0.7 MPa), with a proof pressure of 10 kgf/cm² . A key performance metric is its substantial flow rate of 2886 Nl/min, facilitated by a large effective orifice area of 65 mm²​ . The valve is constructed from a durable aluminum alloy body​ with a nickel-plated coating​ for corrosion resistance.

Order Codes:

Specification:

Dimensions:
