IMI Norgren 2623000 2623001 2623500 2623501 5/2 way Solenoid Valve G1/4 G1/2
Designed for ease of use and longevity, the 26230 and 80107 Series valves include a manual override with detent for safe testing and emergency interventions. The compact design and lightweight aluminum construction allow flexible mounting in space-constrained environments. Their solenoid system is easily interchangeable, minimizing downtime during maintenance. Operating seamlessly in temperatures from -10°C to +50°C, these valves ensure stable performance in varied conditions. With options for 24V DC or 220V AC power and compliance with RoHS standards, they provide a versatile and safe solution for industries like food processing and pharmaceuticals.
Order Codes:
| Item Code |
Port Size |
Position |
| 2623000 |
G1/4 |
5/2 way |
| 2623001 |
G1/4 |
5/2 way |
| 2623500 |
G1/2 |
5/2 way |
| 2623501 |
G1/2 |
5/2 way |
Technical Data:
| Port size |
Actuation/return |
Operating pressure (bar) |
Flow (l/min) |
Weight (kg) |
Dimensions No. |
Solenoid group |
Model *1) |
| G1/4 |
Solenoid/air spring |
1 ... 10 |
1325 |
0,4 |
5 |
B |
2623000 *2) |
| G1/4 |
Solenoid/air spring |
2 ... 8 |
1325 |
0,4 |
5 |
A |
2623001 *2) |
| G1/2 |
Solenoid/air spring |
2 ... 10 |
3300 |
0,7 |
6 |
B |
2623500 *2) |
| G1/2 |
Solenoid/air spring |
2 ... 8 |
3300 |
0,7 |
6 |
A |
2623501 *2) |
*1) When ordering please indicate solenoid, voltage and current type (frequency)
*2) Port 5 cannot be throttled
Solenoids:
Standard voltages (±10%) 24 V DC, 230 V AC. Standard voltages (±10%) 24 V d.c., 230 V a.c., other voltages on request.
*1) Connectors not included in the scope of delivery, see accessories
*2) Maximum +40°C for battery installation
Ex e mb IIC T4 Gb Ex tb IllC T120°C Db I IP 65 (with cable gland) Standard voltages (±10%) 24 V d.c., 230 V a.c., other voltages on request.
*1) Connectors not included in the scope of delivery, see accessories
*2) Maximum +40°C for battery installation
