GEMU MG50 MG65 MG80 MG100 EPDM SGS FDA class Diaphragm kits for GEMU Diaphragm Valves

GEMU MG50 MG65 MG80 MG100 EPDM SGS FDA class Diaphragm kits for GEMU Diaphragm Valves

Crafted with GEMU’s advanced material technology, the MG series diaphragms feature high-quality elastomer compounds  that offer exceptional chemical resistance, broad temperature tolerance, and long-term durability under operating pressures up to 10 bar, ensuring reliable performance in demanding industrial environments while complying with FDA requirements for media contact application. The precision-engineered construction incorporates optimized material thickness and reinforcing fabrics to minimize wear, reduce deformation during steam exposure, and maintain consistent sealing integrity over extended service cycles, significantly lowering replacement frequency and total cost of ownership.

Each application must be analysed before the selection of thediaphragm material. Since the most varied operating conditionsoften prevail within a plant at different locations, it can benecessary to use different valves and materials. In particular,the chemical characteristics and the temperature of the workingmedia often lead to different interactions. The suitability of the materials used must therefore always be examined individuallywith regard to the current resistance list or checked by anauthorised specialist. Only this procedure guarantees that theapplication will operate safely and economically for a longerperiod.

• ***** Highest mechanical load capacity
• 1The diaphragms are applicable as a moisture barrier. The valves concerned must be serviced regularly if steam is applied continuously.
• *MG = Diaphragm size

• * Diaphragm size
• The thread of the diaphragm pin "W" corresponds to Whitworth standard.
