| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | VSVA-B-B52-H-A1-1C1 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD150-200 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 500 pcs per month |
| Type: | VSVA-B-B52-H-A1-1C1 | Part No: | 546696 |
|---|---|---|---|
| Brand: | FESTO | Valve Function: | 5/2 Double Solenoid |
| Type Of Actuation: | Electric | Material Housing: | Die-cast Aluminium |
| High Light: | Electric Festo Solenoid Valves,5/2 Double Solenoid Pneumatic Solenoid Valves,546696 Pneumatic Solenoid Valves |
||
About product
1.Reverse operation.
2.Vacuum operation.
3.Individual electrical connection via square or round plug sockets.
4.Valves can be replaced under pressure using a vertical pressure shut-off plate.
5.High-performance valves in a sturdy metal housing.
Technical Data
| Valve function | 5/2 double solenoid |
| Type of actuation | Electric |
| Valve size | 26 mm |
| Standard nominal flow rate | 1100 l/min |
| Operating voltage | 24V DC |
| Operating pressure | 0.2 MPa ... 1 MPa |
| Operating pressure | 2 bar ... 10 bar |
| Design | Piston gate valve |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP65 NEMA 4 |
| Nominal size | 9 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Conforms to standard | ISO 15407-1 VDMA 24563 |
| Manual override | Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Flow direction | Non-reversible |
| Symbol | 00991005 |
| lap | Positive overlap |
| Signal status display | LED |
| Pilot pressure | 0.3 MPa ... 1 MPa |
| Pilot pressure | 3 bar ... 10 bar |
| Flow rate of valve | 1400 l/min |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5°C-50°C |
| Sound pressure level | 85 dB(A) |
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -5°C-50°C |
| Product weight | 305 g |
| Type of mounting | On sub-base |
| Auxiliary pilot air port 12 | Sub-base size 26 mm to ISO 15407-1 |
| Auxiliary pilot air port 14 | Sub-base size 26 mm to ISO 15407-1 |
| Pilot control interface | To ISO 15218 |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Die-cast aluminium |
| Material screws | Steel Galvanised |
Package picture
There are many models . Please hurry to me!
