| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | VMPA1-M1H-NS-PI |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD60-80 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 200 pcs per month |
| Order No: | 556839 | Model: | VMPA1-M1H-NS-PI |
|---|---|---|---|
| Brand: | FESTO | Valve Function: | 2x3/2-way, Open, Monostable |
| Valve Size: | 10 Mm | Operating Voltage: | 24V DC |
| High Light: | 10mm Electric Solenoid Air Valve,556839 Pneumatic Solenoid Valves,Open Pneumatic Solenoid Air Valve |
||
About product
1.For valve terminal MPA.
2.As individual valve mounted on sub-base.
3.Comprehensive range of valves.
4.Valve replacement is convenient.
Technical Data
| Valve function | 2x3/2-way, open, monostable |
| Type of actuation | Electric |
| Valve size | 10 mm |
| Standard nominal flow rate | 300 l/min |
| Operating voltage | 24V DC |
| Design | Piston gate valve |
| Type of reset | Mechanical spring |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP65 To IEC 60529 |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting Non-detenting |
| Type of piloting | Pilot actuated |
| Flow direction | Reversible |
| Symbol | 00992875 |
| lap | Positive overlap |
| Signal status display | yes |
| Suitability for vacuum | yes |
| Standard nominal flow rate with QS-6 | 300 l/min |
| Switching time off | 16 ms |
| Switching time on | 14 ms |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -20°C-40°C |
| Media temperature | -5°C-50°C |
| Ambient temperature | -5°C-50°C |
| Max. tightening torque for valve mounting | 0.25 Nm |
| Product weight | 56 g |
| Type of mounting | With through-hole |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
Another size as below
| Type | Order no | Price |
| VMPA1-M1H-N-PI | 533348 | USD60-80 |
| VMPA14-M1H-N-PI | 573725 | USD60-80 |
| VMPA2-M1H-N-PI | 537958 | USD60-80 |
| VMPA1-M1H-NS-PI | 556839 | USD60-80 |
| VMPA14-M1H-NS-PI | 575977 | USD60-80 |
| VMPA2-M1H-NS-PI | 568655 | USD60-80 |
| VMPA1-M1H-K-PI | 533347 | USD60-80 |
| VMPA14-M1H-K-PI | 573724 | USD60-80 |
| VMPA2-M1H-K-PI | 537957 | USD60-80 |
| VMPA1-M1H-KS-PI | 556838 | USD60-80 |
| VMPA14-M1H-KS-PI | 575976 | USD60-80 |
| VMPA2-M1H-KS-PI | 568656 | USD60-80 |
| VMPA1-M1H-H-PI | 533349 | USD60-80 |
| VMPA14-M1H-H-PI | 573726 | USD60-80 |
| VMPA2-M1H-H-PI | 537959 | USD60-80 |
| VMPA1-M1H-HS-PI | 556840 | USD60-80 |
| VMPA14-M1H-HS-PI | 575979 | USD60-80 |
| VMPA2-M1H-HS-PI | 568658 | USD60-80 |
Date sheet
There are so many products, welcome to enquire!
Contact Person: Jaren
Tel: 0086-15257858856
Fax: 86-152-57858856
