FESTO ISO cylinder DSBC-40-200-PPVA-N3 1376663 Pneumatic Air Cylinders

Basic Properties

Place of Origin:China
Brand Name:FESTO
Model Number:DSBC-40-200-PPVA-N3

Trading Properties

Minimum Order Quantity:1pc
Price:EXW USD60-70
Standard Packaging:plastic bag, carton,OPP bag
Delivery Time:10-15 working days
Payment Terms:T/T,Western Union,Paypal
Supply Ability:50 pcs per month
Specifications
Brand: FESTO Part No: 1376663
Type: DSBC-40-200-PPVA-N3 Material Bearing: POM
Material Collar Screws: Galvanised Steel
Highlight

GTIN4052568016746 Pneumatic Air Cylinders

,

GTIN4052568016746 ISO cylinder

,

FESTO ISO cylinder

Product Description

FESTO ISO cylinder DSBC-40-200-PPVA-N3 1376663 Pneumatic Air Cylinders

About product

1.The variants can be configured according to individual needs using a modular product system.

2.Wide range of variants provides high level of flexibility.

3.PPV cushioning: pneumatic cushioning, adjustable at both ends.

4.Extensive range of accessories makes it possible to install the cylinder virtually anywhere.

5.Double-acting.


Technical Data

Stroke 200 mm
Piston diameter 40 mm
Piston rod thread M12x1.25
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Conforms to standard ISO 15552
Piston-rod end Male thread
Design Piston Piston rod Profile barrel
Position detection Via proximity switch
Symbol 00991235
Variants Piston rod at one end
Mode of operation Double-acting
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20°C-80°C
Cushioning length 19 mm
Basic weight for 0 mm stroke 740 g
Additional weight per 10 mm stroke 37 g
Type of mounting Via female thread With accessories Either:
Pneumatic connection G1/4
Note on materials RoHS-compliant
Material cover Die-cast aluminium, coated
Material piston seal TPE-U(PU)
Material piston Wrought aluminium alloy
Material piston rod High-alloy steel
Material piston rod wiper TPE-U(PU)
Buffer seal material TPE-U(PU)
Cushioning piston material POM
Material cylinder barrel Smooth-anodised wrought aluminium alloy
Material nut Galvanised steel
Material bearing POM
Material collar screws Galvanised steel


Another stroke as follow

Type Order no Price
DSBC-40-20-PPVA-N3 2123166 USD60-70
DSBC-40-25-PPVA-N3 1376656 USD60-70
DSBC-40-30-PPVA-N3 2123167 USD60-70
DSBC-40-40-PPVA-N3 1376657 USD60-70
DSBC-40-50-PPVA-N3 1376658 USD60-70
DSBC-40-60-PPVA-N3 2123224 USD60-70
DSBC-40-70-PPVA-N3 2123225 USD60-70
DSBC-40-80-PPVA-N3 1376659 USD60-70
DSBC-40-100-PPVA-N3 1376660 USD60-70
DSBC-40-125-PPVA-N3 1376661 USD60-70
DSBC-40-150-PPVA-N3 2123226 USD60-70
DSBC-40-160-PPVA-N3 1376662 USD60-70
DSBC-40-200-PPVA-N3 1376663 USD60-70
DSBC-40-250-PPVA-N3 1376664 USD60-70
DSBC-40-300-PPVA-N3 2123227 USD60-70
DSBC-40-320-PPVA-N3 1376665 USD60-70
DSBC-40-400-PPVA-N3 1376666 USD60-70
DSBC-40-500-PPVA-N3 1376667 USD60-70


Data sheet

FESTO ISO cylinder DSBC-40-200-PPVA-N3 1376663 Pneumatic Air Cylinders

Festo is the world's leading manufacturer of pneumatic and electromechanical systems, components and controllers for process control and factory automation solutions, with more than 55 national headquarters in more than 180 countries/regions.


There are so many kinds. Hurry to call me!
