CP96SDB50-80C CP96SDB50-100C CP96SDB50-125C SMC CP96 Series ISO Cylinder

Product Details:

Place of Origin:	Japan, China
Brand Name:	SMC, AIRWOLF or OEM
Certification:	CE, ISO15552
Model Number:	CP96SDB50-80C, CP96SDB50-100C, CP96SDB50-125C

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	37-39USD
Packaging Details:	Boxes, Cartons, Pallets, Plastic bags
Delivery Time:	1-7 work days
Payment Terms:	T/T,Western Union,Paypal
Supply Ability:	1000 pcs per week

Contact Now

Detailed Product Description

Item Code:	CP96SDB50-80C, CP96SDB50-100C, CP96SDB50-125C	Cylinder Tube Material:	Aluminum Alloy
Piston Rod Material:	Carbon Steel	Working Pressure:	0.05~1.0MPa
Operating Temperature:	Without Auto Switch: –20 To 70°C With Auto Switch: –10 To 60°C	Bore Size:	50mm
Stroke:	80, 100, 125mm	Feature:	Double Acting, Linear Actuator
Highlight:	SMC CP96 Series ISO Cylinder , Pneumatic Air Cylinder with warranty , CP96SDB50 ISO Cylinder for automation

CP96SDB50-80C CP96SDB50-100C CP96SDB50-125C SMC CP96 Series ISO Cylinder

The CP96 Series is designed for broad application across industrial automation, with several specialized variants to meet specific needs. The standard CP96 model serves general-purpose applications in automotive manufacturing, packaging machinery, material handling, and robotic systems . For applications requiring precise angular control, the CP96K series offers a non-rotating rod variant with accuracy of ±0.5° for ø32-ø63 bore sizes and ±0.3° for ø80-ø100 sizes . The C96Y smooth cylinder type is optimized for transfer applications requiring smooth movements at low pressure with reduced piston sliding resistance . For safety-critical applications, the CP96N locking cylinder provides intermediate stop capability and drop prevention with a holding force increased by 15% over previous models . These cylinders are also available in ATEX-compliant versions for use in explosive atmospheres.

Order Codes:

Item Code	Bore Size (ø mm)	Stroke (mm)	Type
CP96SDB50-80C	50	80	Double acting
CP96SDB50-100C	50	100	Double acting
CP96SDB50-125C	50	125	Double acting
CP96SDB50-80	50	80	Double acting
CP96SDB50-100	50	100	Double acting
CP96SDB50-125	50	125	Double acting

Specifications:

Bore size [mm]		32	40	50	63	80	100	125
Action		Double acting
Fluid		Air
Proof pressure		1.5 MPa
Max. operating pressure		1.0 MPa
Min. operating pressure		0.05 MPa
Ambient and fluid temperatures		Without auto switch: -20 to 70°C (No freezing) With auto switch: -10 to 60°C (No freezing)
Lubrication		Not required (Non-lube)
Operating piston speed		50 to 1000 mm/s						50 to 700 mm/s
Allowable stroke tolerance	Up to 500	+2 0						+1.0 0
	501 to 1000	+2.4 0						+1.4 0
	1001 to 1500	+2.8 0						+1.8 0
	1501 to 2000	+3.2 0						+2.2 0
Cushion		Air cushion on both ends + Bumper cushion						Air cushion
Port size		G 1/8	G 1/4	G 1/4	G 3/8	G 3/8	G 1/2	G 1/2
Mounting		Basic, Axial foot, Rod flange, Head flange, Single clevis, Double clevis, Center trunnion, Adjustable position trunnion

Dimensions:

Quality Standards:

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.

Samples:

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

After-sale serivce:

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.

Competitive Advantage:

Our product features:	Our Services Guarantee:
1) Competitive price	1) Prompt respond (Reply with 24 hours)
2) Good quality	2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging	4) 1 year warranty
4) Produce according to Customers’ instruction	5) Photos/videos are available during production.
5) None delay shipment	6) Loading inspection, and send loading photos before shipment.
