AirTAC TR32X80S TR32X90S TR32X100S TR32X125S TR Series Double Acting Twin-rod Cylinder

AirTAC TR32X80S TR32X90S TR32X100S TR32X125S TR Series Double Acting Twin-rod Cylinder

Product Details:
Place of Origin: Taiwan, China
Brand Name: AirTAC, AIRWOLF or OEM
Certification: CE, ISO9001
Model Number: TR32X80S, TR32X90S, TR32X100S, TR32X125S
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: 23-87USD
Packaging Details: Boxes, Cartons, Pallets, Plastic bags
Delivery Time: 1-7 work days
Payment Terms: T/T,Western Union,Paypal
Supply Ability: 1000 pcs per week
Contact Now
Detailed Product Description
Item Code: TR32X80S, TR32X90S, TR32X100S, TR32X125S Body Material: Aluminum
Seal Material: NBR Working Pressure: 0.15~1.0MPa(22~145psi)
Operating Temperature: -20~70℃ Working Medium: Air(to Be Filtered By 40μm Filter Element)
Bore Size: 32mm Function: Double Acting
Highlight:

TR Series double acting air cylinder

,

Twin-rod pneumatic cylinder

,

AirTAC TR32X80S air cylinder

AirTAC TR32X80S TR32X90S TR32X100S TR32X125S TR Series Double Acting Twin-rod Cylinder
The AirTAC TR Series Twin-rod Guided Cylinder adopts extended sliding support guide structure with low deflection of piston rod end and high non-rotating accuracy up to ±0.1°, which ensures ultra-precise linear movement without extra external guide accessories. Adjustable front bumpers are pre-installed to buffer impact and fine-tune effective stroke within a small range. Multi-directional mounting holes on three sides of the fixing plate support top, front and bottom installation modes, while dual air port groups on both sides allow flexible air piping layout for compact automation stations with strict precision requirements.
Order Codes:
Item Code Piston (mm) Stroke (mm) Type
TR32×80S 32 80 Double acting
TR32×90S 32 90 Double acting
TR32×100S 32 100 Double acting
TR32×125S 32 125 Double acting
[Note1] Retract position.
[Note2] PT thread, G thread and NPT thread are available.
Datasheet:
Bore size(mm) 6 10 16 20 25 32
Acting type Double acting
Fluid Air(to be filtered by 40μm filter element)
Operating pressure 0.2~1.0MPa(29~145psi) 0.15~1.0MPa(22~145psi)
Proof pressure 1.5MPa(215psi)
Temperature °C -20~70
Speed range mm/s 30~500
Adjustable stroke mm -5~0
Stroke tolerance ≤100+1.0 0          >100+1.5 0
Cushion type Bumper
Non-rotating tolerance [Note1] ±0.2° ±0.15° ±0.1°
Port size [Note2] M5×0.8 1/8"

Dimensions:
AirTAC TR32X80S TR32X90S TR32X100S TR32X125S TR Series Double Acting Twin-rod Cylinder
