5 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V

5 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V

    • 5 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V
  • 5 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V

    Product Details:

    Place of Origin: Ningbo
    Brand Name: FLY AIRTAC
    Certification: CE, ISO9001
    Model Number: 4V310-08 4V310-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 100
    Price: USD4-12
    Packaging Details: carton,pallet or according to customers' requirement
    Delivery Time: 3 working days after receiving the customers' payment
    Payment Terms: T/T,Western Union, Paypal
    Supply Ability: 15000 pcs per month
    Contact Now
    Detailed Product Description
    Operating Pressure: 0.15-0.8MPa(21-114psi) Media:: Gas
    Postion:: 5 Port 2 Position
    High Light:

    pneumatic operated valves

    ,

    pulse solenoid valve

    DC24V 4V310-10 5/2way 0.15-0.8MPa Solenoid valve Pneumatic Solenoid Valves

    5 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V 0

    Secification:

    Model No: 4V310-08 4V310-10
    Place of Origin: Zhejiang,China (Mainland)
    Power: Pneumatic
    Standard or Nonstandard: Standard
    Pressure: Low Pressure
    Structure: Pilot
    Material: Alloy
    Temperature of Media: Normal Temperature
    Media: Gas
    Brand Name: Airtac SMC ASCO
    Valve type: 5 port 2 position
    Lubrication: Not required
    Temperature °C: -20~70
    Orifice size: 30.0mm2
    Material of body: Aluminum alloy
    Fluid: Air

    5 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V 1



    Specification:

    Model    4V310-08
    4V320-08
    4V330C-08
    4V330E-08
    4V330P-08
    4V310-10
    4V320-10
      4V330C-10
      4V330E-10
      4V330P-10
    Fluid Air(to be filtered by 40pm fillter element)
    Acting Piloted
    Port size ln=Out=Exhaust=1/4" ln=Out=3/8"  Exhaust=1/4"
    Orifice size 25.0mm2

    (Cv=1.40)
    18.0mm2

    (Cv=1.00)
    30.0mm2

    (Cv=1.68)
    18.0mm2

    (Cv=1.00)
    Valve type 5 port 3 position 5 port 2 position 5 port 3 position 5 port 2 position
    Operating pressure 0.15-0.8MPa(21-114psi)
    Proof pressure 1.5MPa(215psi)
    Temperature °C -20-70
    Material of body Aluminum alloy
    Lubrication Not required
    Max.frequency 4 cycle/sec 3 cycle/sec 4 cycle/sec 3 cycle/sec
    Weight 4V310-08:310g 4V320-08:400g 450g 4V310-10:310g 4V320-10:400g 450g



    5 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V 25 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V 3



    No. Item No. Item NO. Item
    1 Connector 9 Wear ring 17 Override spring
    2 Coil net 10 Bottom cover 18 Manual override
    3 Coil 11 Fixed screw 19 Spring holder
    4 Armature 12 Spool spring 20 Return spring
    5 Fixed plate 13 Bottom cover gasket 21 Side cover
    6 Piston 14 Spool O-ring 22 Springholder
    7 Pilotkit 15 Spool
    8 Body 16 Piston O-ring


    Flow chart :

    5 / 2 Way Low Pressure Pneumatic Solenoid Valves 4V310-10 DC24V 4
