Industrial Pneumatic Vibration Motor Continuous Duty Cycle For Animal Feed Milling

Industrial Pneumatic Vibration Motor Continuous Duty Cycle For Animal Feed Milling

    • Industrial Pneumatic Vibration Motor Continuous Duty Cycle For Animal Feed Milling
    • Industrial Pneumatic Vibration Motor Continuous Duty Cycle For Animal Feed Milling
    • Industrial Pneumatic Vibration Motor Continuous Duty Cycle For Animal Feed Milling
    • Industrial Pneumatic Vibration Motor Continuous Duty Cycle For Animal Feed Milling
  • Industrial Pneumatic Vibration Motor Continuous Duty Cycle For Animal Feed Milling

    Product Details:

    Place of Origin: China
    Brand Name: Wamgroup
    Certification: CE
    Model Number: S10

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: Negotiation
    Packaging Details: Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement
    Delivery Time: within 1-30 working days after payment
    Payment Terms: T/T , Western Union
    Supply Ability: 1000 pcs
    Contact Now
    Detailed Product Description
    Model Code: S10 Applies To: Animal Feed Milling
    DUTY CYCLE: Continuous WORKING PRESSURE: 2 Bar To 6 Bar
    PNEUMATIC CIRCUIT: Filter + Flow Control Valve + Lubrification + 3/2 Ways Valve AIR SUPPLY QUALITY: Class 5.4.4.
    WORKING TEMPERATURE: -20 °C To 200 °C TECHNOLOGY: Rotary Vibration - High Frequency
    High Light:

    pneumatic equipment components

    ,

    pneumatic system components

    1. Product name: S10 Oli Wamgroup Pneumatic Oscillator filter sleeve Sreies S industrial pneumatic vibrators



    2. Data

    MODEL VIBRATION F.C. MAX AIR CONSUMPTION
    Vpm 2 bar (29 psi) 4 bar (58psi) 6 bar (87 psi) 2 bar (29 psi) 4 bar (58psi) 6 bar (87 psi)
    2 bar
    (29 psi)
    4 bar
    (58psi)
    6 bar
    (87 psi)
    KG LB KG LB KG LB l/min CF/min l/min CF/min l/min CF/min
    S8 25500 31000 35000 13 29 26 57 36 79 83 2.9 145 5.1 195 6.9
    S10 22500 28000 34000 25 55 47 103 71 156 92 3.2 150 5.3 200 7.1
    S13 15000 18500 22500 32 70 55 121 87 191 94 3.3 158 5.6 225 7.9
    S16 13000 17000 19500 45 99 80 176 110 242 122 4.3 200 7.1 280 9.9
    S20 10500 14500 16500 72 158 122 268 172 378 130 4.6 230 8.1 340 12
    S25 9200 12200 14000 93 205 157 345 205 451 160 5.7 290 10.2 425 15
    S30 7800 9700 12500 151 332 247 543 321 706 215 7.6 375 13.2 570 20.1
    S36 7300 9000 10000 206 453 315 693 405 891 260 9.2 475 16.8 675 23.8




    3. Features

    DUTY CYCLE: Continuous

    WORKING PRESSURE: From 2 bar to 6 bar (from 29 psi to 87 psi)

    PNEUMATIC CIRCUIT: Filter + flow control valve + lubrification + 3/2 ways valve

    AIR SUPPLY QUALITY: Class 5.4.4.

    WORKING TEMPERATURE: From -20 °C to 200 °C (from -4 °F to 392 °F)

    MAX NOISE LEVEL: 90 dB(a)

    TECHNOLOGY: Rotary vibration - high frequency

    ATEX: II 2D C TX, II 2G C TX

    MATERIAL: Aluminium body and zinc plate cover



    4. S - ROTARY PNEUMATIC VIBRATORS - BALL

    APPLICATION: Hopper and silo - screen - vibrating table - chute

    POWDER: Dry and granular

    PROBLEM SOLVING: Friction reduction - separation



    5. Drawing

    Drawing

    DIMENSIONAL SPECIFICATIONS
    MODEL A B C D E F IN-OUT WEIGHT
    mm in mm in mm in mm in mm in mm in kg lb
    S8 50 2 86 3.4 68 2.7 12 0.5 20 0.8 7 0.3 1/8" BSPP 0.13 0.29
    S10 50 2 86 3.4 68 2.7 12 0.5 20 0.8 7 0.3 1/8" BSPP 0.13 0.9
    S13 65 2.6 113 4.5 90 3.5 16 0.6 25 1 9 0.4 1/4" BSPP 0.26 0.57
    S16 65 2.6 113 4.5 90 3.5 16 0.6 28 1.1 9 0.4 1/4" BSPP 0.3 0.66
    S20 80 3.2 128 5.1 104 4.1 16 0.6 33 1.3 9 0.4 1/4" BSPP 0.53 1.17
    S25 80 3.2 128 5.1 104 4.1 16 0.6 38 1.5 9 0.4 1/4" BSPP 0.63 1.39
    S30 100 3.9 160 6.3 130 5.1 20 0.8 45 1.8 11 0.4 3/8" BSPP 1.13 2.49
    S36 100 3.9 160 6.3 130 5.1 20 0.8 50 2 11 0.4 3/8" BSPP 1.34 2.95




    6. Product show

    Industrial Pneumatic Vibration Motor Continuous Duty Cycle For Animal Feed Milling 1



    7. Applies to

    1. Animal Feed Milling

    2. Flour Milling

    3. Paint & Varnish Processing

    4. Plastics Processing



    8. Serves time
    0:00 - 23:59
    From Monday to Sunday



    9. Suit for

    PRODUCT SERIES APPLICATIONS POWDERS FEATURES BENEFITS
    S Silos Dry powders Filter sleeve cleaning Economical
    Hoppers Granules Suitable for outdoor use Low air consumption
    Piping Plastics Resistant to oxidation High frequency vibration
    Chutes Sand Atex II2G c Tx
    Compacting Ashes Atex II2D c Tx
      Cement
      Lime
