1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color

1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color

    • 1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color
    • 1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color
    • 1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color
    • 1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color
  • 1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color

    Product Details:

    Place of Origin: China
    Brand Name: Techno
    Certification: CE
    Model Number: MSV98322EB MSV98322LB

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: Negotiation
    Packaging Details: Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement
    Delivery Time: within 1-30 working days after payment
    Payment Terms: T/T , Western Union
    Supply Ability: 1000 pcs
    Contact Now
    Detailed Product Description
    Model Code: MSV98322EB MSV98322LB Body Material: Aluminum Alloy
    Name: Mechanical Valve Fluid Temperature: -10~60 C
    Color: Red/Black/Green

    1/4" MSV98322EB MSV98322LB 3/2 Way Aluminium Alloy MSV9832 Series Stop Cock Mechanical Valve


    Features

    1. To be installed in moving devices like air cylinder, slide, etc.
    2. Various operating styles.
    3. Panel bore size Φ30(Option Φ25)



    Specification

    Model MSV9832-02
    Port size 1/4"(Option 1/8")
    Body material Aluminum alloy
    Panel dimension 30mm(Option: 25mm)
    Fluid Compressed air
    Sectional area 18mm²
    Operating pressure range 0~9 kgf/cm²
    Max. operating pressure 10 kgf/cm²
    Ambient temperature -10~60℃
    Standard operator color Black: TB, LB; Red: PB, PP, PPL, EB



    1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color
    1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color1/4 Inch Stop Cock Pneumatic Manual Valve MSV98322EB MSV98322LB Red Color
