    Product Details:

    Place of Origin: China
    Certification: CE
    Model Number: HSV06

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: Negotiation
    Packaging Details: Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement
    Delivery Time: within 1-30 working days after payment
    Payment Terms: T/T , Western Union
    Supply Ability: 1000 pcs
    Contact Now
    Detailed Product Description
    Model Code: HSV06 Color: Blue
    Body Material: Aluminum Alloy Name: Hand Slide Valve

    HSV Series Hand slide valve

    Product feature
    1. There are several ways of internal and external thread connection, suitable for the application in different pipeline systems.
    2. The direction-change slides smoothly and has good hand feeling.
    3. There is large effective circulating area.
    4. The valve spool surface is treated with acid washing passivation, and the surface of valve body is oxidized to keep the color for a long time.





    Ordering code



    HSV 08
    Hand slid valve Port size 06: 1/8"  08: 1/4"  10: 3/8"  15: 1/2"  20: 3/4"  25: 1"



    Specification



    Model HSV06 HSV08 HSV10 HSV15 HSV20 HSV25
    Fluid Air (to be filtered by 40um filter element)
    Operating Manual control direct acting type
    Port size 1/8" 1/4" 3/8" 1/2" 3/4" 1"
    Orifice size 23.0mm² (Cv=1.28) 40.0mm² (Cv=2.20) 62.0mm² (Cv=3.50) 140.0mm² (Cv=7.80) 250.0mm² (Cv=13.80) 392.0mm² (Cv=21.78)
    Valve type 3 port 2 position
    Lubrication Not required
    Pressure range 0~1.0MPa(0~145Psi)
    Proof pressure 1.5 MPa (215Psi)
    Temperature -20~70℃
    Material of body Aluminum alloy



    HSV Series Hand slide valve HSV06 HSV08 HSV10 HSV15 Sliding Switch Hand Push ValveHSV Series Hand slide valve HSV06 HSV08 HSV10 HSV15 Sliding Switch Hand Push Valve



    Product show

    HSV Series Hand slide valve HSV06 HSV08 HSV10 HSV15 Sliding Switch Hand Push Valve



    Quality Standards :
    The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections



    Samples
    You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.



    After-sale service
    We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
