|Xikou,Fenghua,Zhejiang Province, Chinaemail@example.com|
|Place of Origin:||China|
|Minimum Order Quantity:||1 piece|
|Packaging Details:||Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement|
|Delivery Time:||within 1-30 working days after payment|
|Payment Terms:||T/T , Western Union|
|Supply Ability:||1000 pcs|
pulse solenoid valve,
pulse jet valve
Nominal Temperature Ranges:
1.Ambient: AC constructions: 0°F to 185°F (-18°C to 85°C).150°F (66°C) maximum for valves with HYT diaphragm.Consult local sales office for DC constructions
2.Fluids: 0°F to 185°F (-18°C to 85°C), except as noted.For temperatures to 300°F (149°C), specify FPM,
suffix “V” (except where noted).Refer to Engineering Section for details.
1.Specially designed for reverse jet-type dust collector systems.
2.High flow Cv’s to 140 for effective bag cleaning.
3.High cycle life.
1.Standard: Watertight, Types 1, 2, 3, 3S, 4, and 4X.
2.Optional: Explosionproof and Watertight, Types 3, 3S, 4, 4X, 6, 6P, 7, and 9.
|Valve Parts in Contact with Fluids|
|Diaphragm||NBR, HYT, or CR, as noted|
|Discs||Discs NBR or PA, as noted|
|Coil insulation class||F|
|Connector specification||DIN 43650, 11 mm, industry, standard B (type 01)
or ISO 4400 (type 02)
|Connector||Spade plug (cable Ø 6-8 mm or Ø 6-10 mm)|
|Electrical safety||IEC 335|
|Standard voltages||DC (=) : 24V
AC (~) : 24V - 115V - 230V / 50 Hz
and Class of
|Watt Rating and Power
|Spare Coil Part No.|
|Watts||VA Holding||VA Inrush||AC||AC|
|Standard Voltages: 24, 120, 240, 480 volts AC, 60 Hz (or 110, 220 volts AC,
50 Hz). Consult factory for DC voltage. Other voltages are available when
The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount, but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance, according to the original quality standards, during warranty with product problems, need confirmation testing by the manufacturer, the supplier to be solved, the demand side due to storage, use, poor maintenance caused by lower-quality product, and not raise objections.
