| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | VUVG-BK10-M52-AT-F-1H2L-S |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD50-60 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100 pcs per month |
| Brand: | FESTO | Order No: | 8042555 |
|---|---|---|---|
| Model: | VUVG-BK10-M52-AT-F-1H2L-S | Valve Function: | 5/2-way, Monostable |
| Operating Voltage: | 24V DC | Type Of Actuation: | Electric |
| High Light: | Monostable Air Operated Solenoid Valve,Pneumatic Solenoid Valves 8042555,24V DC Electric Solenoid Air Valve |
||
About product
1.5/2-way valve, single solenoid.
2.Internal pilot air supply.
3.Pneumatic spring return.
Technical Data
| Valve function | 5/2-way, monostable |
| Type of actuation | Electric |
| Valve size | 10 mm |
| Standard nominal flow rate | 160 l/min |
| pneumatic working port | Flange |
| Operating voltage | 24V DC |
| Design | Piston slide with sealing ring |
| Type of reset | Pneumatic spring |
| Approval | c UL us - Recognized (OL) |
| Certificate issuing authority | UL MH19482 |
| Degree of protection | IP40 |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Flow direction | Non-reversible |
| Symbol | 00992908 |
| lap | Positive overlap |
| Signal status display | LED |
| Max. switching frequency | 2 Hz |
| Switching time off | 17 ms |
| Switching time on | 14 ms |
| Duty cycle | 100% |
| Characteristic coil data | 24 V DC: 0.8 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Media temperature | -5°C-50°C |
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -5°C-50°C |
| Product weight | 45 g |
| Electrical connection | 2-pin Plug pattern H, horizontal connection Plugs |
| Type of mounting | On manifold rail With through-hole |
| Pneumatic connection, port 2 | Flange |
| Pneumatic connection, port 4 | Flange |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Wrought aluminium alloy |
Another size
| Type | Order no | Price |
| VUVG-BK10-T32C-AT-F-1R8L-S | 8042558 | USD50-60 |
| VUVG-BK10-M52-AT-F-1R8L-S | 8042559 | USD50-60 |
| VUVG-BK10-B52-T-F-1R8L-S | 8042560 | USD50-60 |
| VUVG-BK10-T32C-AT-F-1H2L-S | 8042554 | USD50-60 |
| VUVG-BK10-M52-AT-F-1H2L-S | 8042555 | USD50-60 |
| VUVG-BK10-B52-T-F-1H2L-S | 8042556 | USD50-60 |
Dimensions
There are so many products, welcome to enquire!
