Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings

Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings

  • Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings
  • Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings
  • Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings
  • Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings
Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings
Product Details:
Place of Origin: CHINA
Brand Name: CAMOZZI
Certification: CE
Model Number: 1590 5/3
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement
Delivery Time: within 1-10 working days after payment
Payment Terms: T/T , Western Union, PayPal
Supply Ability: 1000 pcs /day
Contact Now
Detailed Product Description
Model: 1590 5/3 Port Size: 5/3
Color: Silvery Temperature: -20°C ~ 80°C
Material: Nickel-plated Brass
High Light:

pneumatic fittings and tubing

,

brass tube fittings

Pneumatic Tube Fittings CAMOZZI S6440 Series Silvery Lateral Swivel Male Tee Sprint



Tube external diameters: 3, 4, 5, 6, 8, 10, 12, 14, 16 mm

Fittings Mod. 1590 Bulkhead Union Reducer

Temperatur Relative pressure
In the catalogue °C is used as the unit for
the working temperature range.

In the catalogue bar is used as the unit
for the working pressure range.
1 bar = 14,5 psi = 105 Pa

0,07 bar = 1 psi

°C °F bar psi
-0,95 -14,00
-0,80 -11,50
-20 -4 0 0
-10 14 0.5 7
0 32 1 14.5
60 140 10 145
80 176 15 217
120 248 24 348
200 392 100 1450



GENERAL DATA
Diameters ø 4 - 5 -6 - 8 - 10 - 12 - 14 - 16 mm
Micro models: ø 3 - 4 - 6 - 8 - 10 mm
Threads GAS conical ISO 7 (BSPT) GAS cylindrical ISO 228 (BSP); M5-M6 and other metric threads available on request; NPT on request
Micro models: M3 - M5 - M7 - G1/8 - G1/4
Pressure standard models: min -0,9 bar - max 16 bar (see tubing)
models with self-retaining device: 0 ÷ 16 bar
Tube to connect Rilsan, PA 6-11-12, Polyethylene, PU, Hytrel Polyester
Fluid compressed air (for other types of fluid, contact our engineers
Temperature -20°C ÷ 80°C (see the technical data of tubing used)
Micro models: -10°C ÷ 80°C (see the technical data of tubing used)
Materials standard models: body and collet in nickel-plated brass, O-Ring in NBR,
thread seals in PTFE - NBR - PA
models with self-retaining device: body and collet in nickel-plated brass,
poppet valve in brass, spring in stainless steel, O-Ring in NBR,
thread seals in PTFE



Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings 0

Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings 1

Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings 2Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings 3Series 1000 Swivel Male Tee Sprint , Silvery Tube Rapid Brass Pneumatic Fittings 4



Packing:Plastic bags, boxes, cartons, and pallets. Meantime, we can pack the goods according to customers' special requirements.
