| Brand Name: | FESTO |
| Model Number: | DSBC-40-50-PPVA-N3 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD60-70 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 500 pcs per month |
| Brand: | FESTO | Part No: | 1376658 |
|---|---|---|---|
| Type: | DSBC-40-50-PPVA-N3 | Stroke: | 50 Mm |
| Piston Diameter: | 40 Mm | Piston Rod Thread: | M12x1.25 |
| High Light: | DSBC-40-50-PPVA-N3,1376658 Pneumatic Air Cylinders,Male Thread Pneumatic Air Cylinders |
||
About product
Stroke:50 mm
Piston diameter:40 mm
Piston rod thread:M12x1.25
Wide range of variants provides high level of flexibility
The variants can be configured according to individual needs using a modular product system
Technical Data
| Stroke | 50 mm |
| Piston diameter | 40 mm |
| Piston rod thread | M12x1.25 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 15552 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 6 according to ISO 14644-1 |
| Ambient temperature | -20°C-80°C |
| Cushioning length | 19 mm |
| Basic weight for 0 mm stroke | 740 g |
| Additional weight per 10 mm stroke | 37 g |
| Type of mounting | Either: Via female thread With accessories |
| Pneumatic connection | G1/4 |
| Note on materials | RoHS-compliant |
| Material coverDie-cast aluminium, coated | Die-cast aluminium, coated |
| Material piston seal | TPE-U(PU) |
| Material pistonWrought aluminium alloy | Wrought aluminium alloy |
| Material piston rod | High-alloy steel |
| Material piston rod wiper | TPE-U(PU) |
| Buffer seal material | TPE-U(PU) |
| Cushioning piston material | POM |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
| Material nut | Galvanised steel |
| Material bearing | POM |
| Material collar screws | Galvanised steel |
There are so many models. Please contact with me!
Contact Person: Jaren
Tel: 0086-15257858856
Fax: 86-152-57858856
