| Brand Name: | FESTO |
| Model Number: | DYSC-5-5-Y1F |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | USD50-60 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000pcs per month |
| Part No: | 548011 | Type: | DYSC-5-5-Y1F |
|---|---|---|---|
| Brand: | FESTO | Size: | 5 |
| Stroke: | 5 Mm | Cushioning: | Self-adjusting |
About Product
Hydraulic shock absorber with rapidly increasing cushioning force curve
Corrosion resistance class CRC:2 - Moderate corrosion stress
LABS (PWIS) conformity:VDMA24364-B2-L
Ambient temperature: -10°C-80°C
Material housing:High-alloy steel
Technical Data
| Size | 5 |
| Stroke | 5 mm |
| Cushioning | Self-adjusting |
| Mounting position | optional |
| Position detection | Without |
| Symbol | 00991497 |
| Mode of operation | Single-acting Pushing |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -10°C-80°C |
| Cushioning length | 5 mm |
| Product weight | 9 g |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | High-alloy steel |
| Material piston rod | High-alloy steel |
There are so many models ,please contact with me.
