| Brand Name: | FESTO |
| Model Number: | MFH-5-1/2 |
| Minimum Order Quantity: | 1 PC |
|---|---|
| Price: | USD 60-80 |
| Packaging Details: | Box, Carton 16X6X3.5 CM |
| Delivery Time: | 7 working Days |
| Payment Terms: | T/T, Western Union, MoneyGram Paypal |
| Supply Ability: | 50 PCS Per Week |
| Product Weight: | 1135 G | Part No: | 6420 |
|---|---|---|---|
| Model No: | MFH-5-1/2 | Valve Function: | 5/2-way, Monostable |
| Type Of Actuation: | Electric | Brand: | FESTO |
| High Light: | 6420 Festo Solenoid Valves,Pneumatic Solenoid Valves MFH-5-1/2,Pneumatic Solenoid Valves 5/2-Way |
||
Very sturdy poppet valve concept for all 3/2 and 5/2-way valves
Solenoid coil not included in scope of delivery
Solenoid coil can be easily exchanged later
Technical data
| Valve function | 5/2-way, monostable |
| Type of actuation | Electric |
| Construction width | 52 mm |
| Type of reset | Mechanical spring |
| Degree of protection | IP65 |
| Nominal size | 14 mm |
| Grid dimension | 69 mm |
| Sealing principle | Soft |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -20°C-60°C |
| Media temperature | -10°C-60°C |
| Ambient temperature | -5°C-40°C |
| Product weight | 1135 g |
| Pilot exhaust port 84 | M5 |
| Pneumatic connection, port 1 | G1/2 |
| Pneumatic connection, port 2 | G1/2 |
| Pneumatic connection, port 3 | G1/2 |
| Pneumatic connection, port 4 | G1/2 |
| Pneumatic connection, port 5 | G1/2 |
| Note on materials | RoHS-compliant |
| Material seals | NBR TPE-U(PU) |
| Material housing | Die-cast aluminium |
There are so many models ,please contact with me.
Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.
