| Brand Name: | FESTO |
| Model Number: | DSBC-63-150-PPVA-N3 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD100-120 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1000pcs per month |
| Type: | DSBC-63-150-PPVA-N3 | Brand: | FESTO |
|---|---|---|---|
| Part No: | 2125494 | Mode Of Operation: | Double-acting |
| Ambient Temperature: | -20°C-80°C | Material Bearing: | POM |
| High Light: | 2125494 Pneumatic Air Cylinders,POM ISO Cylinder,ISO Double Acting Pneumatic Air Cylinders |
||
About product
LABS (PWIS) conformity:VDMA24364-B1/B2-L
Cushioning length:22 mm
Type of mounting:Either: Via female thread With accessories
Technical Data
| Stroke | 150mm |
| Piston diameter | 63 mm |
| Piston rod thread | M16x1.5 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 15552 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Cushioning length | 22 mm |
| Basic weight for 0 mm stroke | 1740 g |
| Additional weight per 10 mm stroke | 62 g |
| Type of mounting | Either: Via female thread With accessories |
| Pneumatic connection | G3/8 |
| Note on materials | RoHS-compliant |
| Material cover | Die-cast aluminium, coated |
| Material piston seal | TPE-U(PU) |
| Material piston | Wrought aluminium alloy |
| Material piston rod | High-alloy steel |
| Material piston rod wiper | TPE-U(PU) |
| Buffer seal material | TPE-U(PU) |
| Cushioning piston material | POM |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
| Material nut | Galvanised steel |
| Material bearing | POM |
| Material collar screws | Galvanised steel |
Mounting components and accessories
There are so many kinds. Please contact with me.
Contact Person: Jaren
Tel: 0086-15257858856
Fax: 86-152-57858856
