Place of Origin: | China |
Brand Name: | FESTO |
Model Number: | SV-3-M5 |
Minimum Order Quantity: | 1pc |
---|---|
Price: | EXW USD20-30 |
Packaging Details: | Plastic bag, Carton |
Delivery Time: | 7-10working days |
Payment Terms: | T/T, Western Union, Paypal |
Supply Ability: | 1000 pcs per month |
Brand: | FESTO | Part No: | 6817 |
---|---|---|---|
Type: | SV-3-M5 | Valve Function: | 3/2-way, Closed, Monostable |
Type Of Actuation: | Manual | Type Of Reset: | Mechanical Spring |
High Light: | Pneumatic System Festo Front Panel Valve,SV-3-M5 Pneumatic System Components |
About product
1.Polymer design.
2.For actuator attachments such as pushbutton actuators, mushroom pushbuttons, mushroom pushbuttons with detent, selector switches or toggle switches.
3.Reliable coupling system for quick mounting and dismounting.
Technical Data
Valve function | 3/2-way, closed, monostable |
Type of actuation | Manual |
Standard nominal flow rate | 65 l/min |
Design | Poppet valve with spring return |
Type of reset | Mechanical spring |
Nominal size | 2 mm |
Sealing principle | Soft |
Mounting position | optional |
Type of piloting | Direct |
Flow direction | Non-reversible |
Symbol | 00991292 |
lap | Positive overlap |
LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Ambient temperature | -10°C-60°C |
Product weight | 40 g |
Type of mounting | Front panel mounting With through-hole |
Pneumatic connection, port 1 | M5 |
Material seals | NBR |
Material housing | Polymer Brass |
Quality Standards
The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount, but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance, according to the original quality standards, during warranty with product problems, need confirmation testing by the manufacturer, the supplier to be solved, the demand side due to storage, use, poor maintenance caused by lower-quality product, and not raise objections.
There are many models . Please contact me!
