| Brand Name: | FESTO |
| Model Number: | LFR-1/2-D-5M-MIDI-A |
| Minimum Order Quantity: | 1 PC |
|---|---|
| Price: | USD 40-50 |
| Packaging Details: | Plastic bags, boxes, cartons |
| Delivery Time: | 7-10 working Days |
| Payment Terms: | T/T, Western Union, MoneyGram Paypal |
| Supply Ability: | 200 PCS Per Week |
| Grade Of Filtration: | 5µm | Product Weight: | 900 G |
|---|---|---|---|
| Model No: | LFR-1/2-D-5M-MIDI-A | Part No: | 162730 |
| Brand: | FESTO | LABS (PWIS) Conformity: | VDMA24364-B1/B2-L |
| High Light: | Pneumatic System Filter Regulator,162730 FESTO Filter Regulator,Pneumatic System Components LFR-1/2-D-5M-MIDI-A |
||
About Product
Two pressure gauge connections for different installation options
Lockable rotary knob
With manual, semi-automatic or fully automatic condensate drain
Technical data
| Size | Midi |
| Series | D |
| Actuator lock | Rotary knob with detent |
| Grade of filtration | 5 µm |
| Condensate drain | Fully automatic |
| Design | Filter regulator with pressure gauge |
| Bowl guard | Metal bowl guard |
| Symbol | 00991583 |
| Standard nominal flow rate | 2600 l/min |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -10°C-60°C |
| Media temperature | 5°C-60°C |
| Ambient temperature | 5°C-60°C |
| Product weight | 900 g |
| Pneumatic connection, port 1 | G1/2 |
| Pneumatic connection, port 2 | G1/2 |
| Note on materials | RoHS-compliant |
| Material housing | Die-cast zinc |
| Material bowl | PC |
There are so many models ,please contact with me.
