| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | QST-6 |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | EXW USD4-5 |
| Packaging Details: | plastic bag, carton |
| Delivery Time: | 7-12 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 6000 pcs per week |
| Specifications: | QST-6 | Brand: | FESTO |
|---|---|---|---|
| Order No: | 153129 | Colour Of Release Ring: | Blue |
| Product Weight: | 11 G | LABS (PWIS) Conformity: | VDMA24364-B1/B2-L |
| High Light: | 153129 Push In T-Connector,Alloy Stainless Steel Festo T-Connector,QST-6 Pneumatic Tube Fittings |
||
About product
LABS (PWIS) conformity:VDMA24364-B1/B2-L
Pneumatic connection, port 1:For tubing outside diameter of 6 mm
Pneumatic connection, port 2:For tubing outside diameter of 6 mm
Note on materials: RoHS-compliant
Material release ring:POM
Product Technical Data
| Size | Standard |
| Nominal size | 4.8 mm |
| Mounting position | optional |
| Design | T-shape |
| Size of pack | 10 |
| Design | Push-pull principle |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-80°C |
| Product weight | 11 g |
| Pneumatic connection, port 1 | For tubing outside diameter of 6 mm |
| Pneumatic connection, port 2 | For tubing outside diameter of 6 mm |
| Colour of release ring | Blue |
| Note on materials | RoHS-compliant |
| Material housing | PBT |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
Festo Core Range Solves the majority of your automation tasks!
There are so many models.Welcome to enquiry !
