| Place of Origin: | China |
| Brand Name: | FESTO |
| Model Number: | MVH-5/3E-1/4-B |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD180-200 |
| Packaging Details: | Plastic bag, Carton |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100 pcs per month |
| Model: | MVH-5/3E-1/4-B | Order No: | 19139 |
|---|---|---|---|
| Brand: | FESTO | Product Weight: | 660 G |
| Material Housing: | Die-cast Aluminium | Valve Function: | 5/3 Exhausted |
| High Light: | 5/3 Exhausted Electric Air Valve,MVH-5/3E-1/4-B Pneumatic Solenoid Valves,Aluminium Air Solenoid Valve |
||
About product
1.Solid structure, reliable performance.
2.In accordance with ATEX directive specific type,Can be used to potentially explosive dangerous job occasion.
3.Multi-function and flexibility, or from the side In front of the installation.
Technical Data
| Valve function | 5/3 exhausted |
| Type of actuation | Electric |
| Construction width | 32 mm |
| Standard nominal flow rate | 1600 l/min |
| pneumatic working port | G1/4 |
| Design | Piston gate valve |
| Type of reset | Mechanical spring |
| Nominal size | 10 mm |
| Grid dimension | 33 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Flow direction | Non-reversible |
| Symbol | 00991036 |
| lap | Positive overlap |
| b value | 0.38 |
| C value | 6.35 l/sbar |
| Max. switching frequency | 3 Hz |
| Switching time off | 38 ms |
| Switching time on | 36 ms |
| Switching time reversal | 46 ms |
| Characteristic coil data | 24 V DC: 2.5 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -40°C-60°C |
| Media temperature | -5°C-50°C |
| Ambient temperature | -5°C-50°C |
| Product weight | 660 g |
| Type of mounting | On PR rail With through-hole Either: |
| Pilot exhaust port 82 | M5 |
| Pilot exhaust port 84 | M5 |
| Pilot air port 12 | G1/8 |
| Pilot air port 14 | G1/8 |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Pneumatic connection, port 3 | G1/4 |
| Pneumatic connection, port 4 | G1/4 |
| Pneumatic connection, port 5 | G1/4 |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
Another Size as below,
| Type | Order no | Price |
| MVH-5/3E-1/8-B | 30478 | USD180-200 |
| MVH-5/3E-1/4-B | 19139 | USD180-200 |
| MVH-5/3E-3/8-B | 14943 | USD180-200 |
| MVH-5/3E-1/8-S-B | 30998 | USD180-200 |
| MVH-5/3E-1/4-S-B | 31005 | USD180-200 |
| MVH-5/3E-3/8-S-B | 15344 | USD180-200 |
There are so many products, welcome to enquire!
