| Brand Name: | FESTO |
| Model Number: | NPQH-T-Q10-E-P10 |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | EXW USD3-5 |
| Packaging Details: | plastic bag, carton |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 1500 pcs per week |
| Specifications: | NPQH-T-Q10-E-P10 | Order No: | 578383 |
|---|---|---|---|
| Brand: | FESTO | Material Housing: | Brass, Chemically Nickel-plated |
| Thrust Ring Material: | PEI | Design: | Push-pull Principle |
| High Light: | 578383 Pneumatic Tube Fittings,PEI Push In T Connector,Festo Push In T Connector |
||
About product
Design:Push-pull principle
LABS (PWIS) conformity:VDMA24364-B1/B2-L
Material housing:Brass, chemically nickel-plated
Technical Data
| Size | Standard |
| Nominal size | 9 mm |
| Tubing insertion depth | 18.3 mm |
| Mounting position | optional |
| Design | T-shape |
| Size of pack | 10 |
| Design | Push-pull principle |
| Symbol | 00997424 |
| Certificate issuing authority | NSF C0523185 |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 4 according to ISO 14644-1 |
| Product weight | 39.8g |
| Pneumatic connection, port 1 | For tubing outer diameter of 10 mm |
| Pneumatic connection, port 2 | For tubing outer diameter of 10 mm |
| Note on materials | RoHS-compliant |
| Material housing | Brass, chemically nickel-plated |
| Guard ring material | PEI |
| Material release ring | Brass, chemically nickel-plated |
| Material tubing seal | FPM |
| Material tubing clamp component | High-alloy stainless steel |
| Thrust ring material | PEI |
Attention
1.Before you endorse the parcel, please do open the package, and check out whether the items are damaged during the shipping process.
If so, please do refuse to sign for the parcel, the courier will send back the package to our company. Otherwise we are not responsible for this...
2.Any order is welcome. we will give discounts and combined shipping costs for you if you order more or mix order. If you have any questions.
please feel free to contact us.
There are so many models.Welcome to enquiry !
