K2016 K2017 Repair Kits NBR / fluororubber Diaphragm And Spring RCAC20T3 ST3 DD3 FS3

K2016 K2017  Repair Kits NBR / fluororubber Diaphragm And Spring RCAC20T3 ST3 DD3 FS3

Ordering Code: K2016(NBR)  K2017(fluororubber)

Fit for: RCAC20T3 ST3 DD3 FS3

Superior performance, easy maintenance diaphragm valve available with threaded ports (T3), dresser nut ports (DD3) or flange and slide ports (FS3). Outlet at 90° to inlet. 3 Series valves are available as remote pilot valves

and may be converted to integral pilot applications through the use of the screw in pilots of the MIP and 3DS series. All 3 Series valves are supplied with CASTEC® protection, offering 500 hours resistance to salt spray.

Suitable for

Dust collector applications, in particular for reverse pulse jet filter cleaning and its variations including bag filters, cartridge filters, envelope filters, ceramic filters, and sintered metal
fibre filters.

Description:

1. The diaphragm repair kits is for FLY/AIRWOLF pulse jet valves

RCAC20T3 ST3 DD3 FS3

2. Material: NBR/fluororubber

3. This repair kit has large air - outlet , so the air can get throgh very smoothly.

4. We use high quality material , the collection equipment efficiency can be improved , the energy loss also can be reduced.

5. FLY/AIRWOLF K2016 K2017 repair kit has unique geometric diaphragm design , high speed from multiple diaphragm to reach the highest peak in an instant.

6. We use high quality material , the collection equipment efficiency can be improved , the energy loss also can be reduced.

7. Its lifespan is about 1 million cycles.

Installation

For your safety do not pressurise system until all valves and pipes are fully secured. Do not attempt to remove a fitted valve while system is under pressure.
1.  Prepare supply and blowtube pipes* to suit valve type and specification. Avoid installing valves underneath the tank.
2.  Ensure tank and pipes are free from dirt, rust or other particulate.
3.  Ensure supply air is clean and dry.
4.  Mount valves to inlet pipes (or flanges, tighten bolts to 10Nm) and blowtube to valves, ensuring no excess thread sealant can enter the valve itself. Ensure blowtube is fully inserted into the valve outlet.
5.  Tanks and pipes must be independently restrained from FS and DD valves.
6.  Connect RCAC pilot port to remote pilot valve, or install MIP/3DS screw in pilot valve.
7.  Apply moderate pressure to system and check for installation leaks.
8.  Fully pressurise system.
9.  Test fire and listen for proper actuation and crisp pulse noise.
Valve is not a structural component. Do not rely on valve to retain tanks or pipe. Refer to Camlock product specifications for installation details.

Competitive Advantage:

Quality Standards :

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections

Warranty:

All item Comes with Basic 3 Month Sellers Warranty, if item defective in 3 Month, We will offer replacement without extra Charger(including shipping fee)After we Receive the Defective item.
If item Defective after 3 Month, Buyers can still send it back, We will contact suppliers or Manufactory for Warranty. Buyers Might Need to pay the Shipping fee For resend the replaced item.
